Installation
Task
Remote Data Port devices
Printer or other output device(s)
Network devices
Wire the Signaling Line Circuits.
7.
Calculate the proper battery rating.
8.
Install main power supply & batteries in
9.
separate enclosure. Run cable to main
& optional power supplies, DC power
outputs, relays, etc.
WARNING:
!
Do not activate power at this time. Do NOT connect batteries.
Main power supply.
Auxiliary power supply and/or
external battery charger
Check that all mounting holes are secured to insure a proper Earth Ground connection.
10.
Connect wire shielding to Earth Ground.
11.
Remove insulator from lithium battery
12.
on CPU
Apply AC power to the control panel by placing the external circuit breaker to the ON position.
13.
Do NOT connect batteries until AC power is checked (see next step).
Check AC power.
14.
Connect the batteries using interconnect cable as described in power supply manual.
15.
Install the dress panels, doors and
16.
covers.
Program the control panel.
17.
Field test the system.
18.

3.3 Mounting a Cabinet

This section provides instructions for mounting the CAB-4 Series backbox to a wall. Follow these
guidelines when mounting the backbox:
• Locate the backbox so that the top edge is 66 inches (1.6764 m) above the surface of the
finished floor.
• Allow sufficient clearance around cabinet for door to swing freely. (See Section 2.4 "System
Cabinets".)
• Use the four holes in the back surface of the backbox to provide secure mounting (See Figure
3.1).
• Mount the backbox on a surface that is in a clean, dry, vibration-free area.
CAUTION:
!
Unless you are familiar with the placement of components within this backbox, only use the
knockout locations provided for conduit entry.
Follow the instructions below.
1. Mark and pre-drill holes for the top two keyhole mounting bolts.
20
Refer to:
LCD-160 Manual
Section 3.18 "Installing Printers"
Noti•Fire•Net Version 4.0 & Higher Manual
Installation document for specific device(s)
Section 3.19 "Wiring a Signaling Line Circuit (SLC)" and the
the Johnson Controls
Main Power Supply Manual
Section 3.15 "Connecting Power Sources and Outputs"
Section 3.16 "UL Power-limited Wiring Requirements"
Main Power Supply Manual
BB-100/200 Cabinet Installation Instructions
Auxiliary power supply manuals and/or battery charger
manuals Note: If using multiple power supplies with one set
of batteries, refer to main power supply manual for
connection requirements.
Section 3.5.1 "Memory-Backup Battery"
Section 3.15.3 "Checking AC Power"
CAB-3/CAB-4 Series Cabinet Installation Document
Programming Manual.
Section 5 "Testing the System"
Table 3.1 Installation Checklist (2 of 2)
IFC-3030 Installation Manual — P/N 52024:C 08/05/2005
, and/or
SLC Wiring Manual
Mounting a Cabinet
