Attaching Panel Circuit Modules
Top
Slot
Chassis
Figure 3.8 Inserting a Two-Layer Module into CHS-4N or CHS-M3 Chassis
NOTE: Depending on system components, clearance may be tight. Do not force modules! Move
the assembly around gently until you find the angle where components and mounting studs pass
each other without scraping together.
IFC-3030 Installation Manual — P/N 52024:C 08/05/2005
Bottom
Slots
Installation
Module
Screw
27
