NFPA 72 Proprietary Fire Alarm Systems
4.4 NFPA 72 Proprietary Fire Alarm Systems
When connected and configured as a protected premises unit with monitor and relay modules, the
IFC-3030 will automatically transmit General Alarm, General Trouble, General Supervisory, and
Security signals to a listed compatible Protected Premises Receiving Unit. A simplified drawing of
connections between the receiving unit and the IFC-3030 protected premises unit is shown in
Figure 4.3.
Connect the receiving unit to the protected premises unit as shown in Section 4.3 "NFPA 72
Central or Remote Station Fire Alarm System (Protected Premises Unit)".
Install and program the Receiving unit with type codes and zone mappings shown in Figure 4.3; see
the programming manual for procedures.
SLC Loop
(twisted-pair
wiring)
Receiving Unit
Compatible With IFC-3030
PRN series
UPS
printer
Note: Remote printers require 120 VAC, 50/60Hz primary power. A secondary power source (battery backup) is not provided; the use
of a separate Uninterruptable Power Supply (UPS) 50 watt minimum, UL-listed for Fire Protective Signaling is recommended. A UPS
is required for NFPA 72-1999 Proprietary Protected Premises Receiving Unit Applications.
Receiving Unit
SLC Loop IN
Figure 4.3 Typical Proprietary Fire Alarm Systems Wiring Connections
IFC-3030 Installation Manual — P/N 52024:C 08/05/2005
Block View
Monitor Modules
Type code: Monitor
Type code: Security-L
Type code: Superv
Type code: Trouble Mon
Detail View
Monitor Module
0
9
9
0
6 7
6 7
8 9
8 9
5
10
10
5
4
4
11
11
8
8
1
1
12
3
3
12
13
2
2
13
1
14
1
14
7
7
0
0
15
15
2
2
TENS
TENS
6 7
6 7
8 9
8 9
5
5
6
6
3
3
4
4
3
3
2
2
5
1
1
4
5
4
0
0
ONES
ONES
A DD R ESS
L OOP
L OOP
A DD R ESS
Receiving Unit
SLC Loop OUT
Relay Modules
Type code: Relay
Zone mapping: Z000
Type code: Relay
Zone mapping: ZF03
Type code: Relay
Zone mapping: ZF04
Type code: Relay
Zone mapping:
ZF01 & ZF02
Relay Module
ELR-47K
0
9
9
0
6 7
6 7
8 9
8 9
5
10
10
5
4
4
11
11
8
8
1
1
12
3
3
12
13
2
2
13
1
14
1
14
7
7
0
0
15
15
2
2
TENS
TENS
6 7
6 7
8 9
8 9
5
5
6
6
3
3
4
4
3
3
2
2
5
1
1
4
5
4
0
0
ONES
ONES
A DD R ESS
L OOP
L OOP
A DD R ESS
Applications
SLC Loop
(twisted-pair
wiring)
IFC-3030
Protected Premises Unit
PPU SLC Loop IN
PPU SLC
Loop OUT
51
