Applications
4.5.6 Wiring for Proprietary Security Alarm Applications
Typical wiring for proprietary security alarm applications with the M300MJ module.
Note the following:
• The module is programmed with one of five type codes (see Section 4.5.2 "General Security
Requirements").
• Supplementary use only applies to UL-listed systems.
• NAC devices used for security cannot be shared with fire NAC devices.
• Refer to the Device Compatibility Document for compatible NAC devices.
• All monitor modules used for security application must be installed in the control panel cabinet
with STS-1 Security Tamper Switch.
47K
End-of-Line
Resistor
IFC-3030 Protected Premises Unit
SLC
(+)
Channel
(-)
A or B
14
12
13
54
UL-listed,
normally-open
security switch
UL-listed, normally-closed
security switch
B- B+ B- B+
B- B+ B+ B-
SW101 SW 201
SW202 SW302 SW402
0
1
5
SW1
XP5-M
Figure 4.5 Wiring Diagram for Proprietary Security Alarm Applications
IFC-3030 Protected Premises Unit
9 0
7 8
9
6
10
5
11
4
8
1
12
3
13
2
1 14
0 15
7 2
TENS
8
7
6 9
5
6
3
4
3
2
1
5 4
0
ONES
LOOP ADDRESS
M300MJ
UL-listed,
normally-open
security switch
B+
UL-listed, normally-closed
security switch
UL-listed,
normally-open
security switch
UL-listed, normally-closed
security switch
IFC-3030 Installation Manual — P/N 52024:C 08/05/2005
Fire/Security Applications
SLC
–
Channel
A or B
+
47K
End-of-Line
Resistor
