System Cabinets

2.4 System Cabinets
The CPU and modules are installed in a CAB-4 series backbox. There are four different sizes
available, holding from one to four rows of equipment plus batteries (up to two 25AH batteries).
Backboxes are ordered separately from doors. The doors can be mounted on the left or the right
side of the cabinet; reversible hinges are provided so that this choice can be made in the field.
Doors open a full 180 degrees and have locks. Mounting methods include surface-mounting or
semi-flush mounting on a wall between 16 inch (406.4 mm) on-center studs. A trim ring option is
available for semi-flush mounting.
External measurements for each cabinet size are provided below. Refer to CAB-3/CAB-4 Series
Cabinet Installation Document (shipped with your cabinet) for specific mounting drawings and
dimensions.
A-size backbox
(one row)
B-size backbox
(two rows)
C-size backbox
(three rows)
D-size backbox
(four rows)
The CPU and adjacent first-row modules mount in chassis CHS-M3. Additional rows of modules
mount in the cabinet using CHS-4N (shipped in kit CHS-4MB), CHS-4L, or other chassis
compatible with CAB-4 series enclosures.
Some additional components available in the CAB-4 series include:
DP-DISP An Inner Dress Panel for covering the backbox area surrounding various modules.
BMP-1 Blank Module Plate for covering an unused module position. Provides another location
for mounting option boards such as TM-4 or NCM-W.
MP-1B Blank panel for covering panel circuit modules in second, third, or fourth rows of
backbox.
BP-4 Battery dress panel.
DP-1B High-profile battery cover
ADP-4B Annunciator dress panel
IFC-3030 Installation Manual — P/N 52024:C 08/05/2005
24.125 in (612.78 mm) wide
20.125 in (511.18 mm) tall
5.218 in (132.54 mm) deep
Optional trim ring TR-A4
24.125 in (612.78 mm) wide
28.625 in (727.08 mm) tall
5.218 in (132.54 mm) deep
Optional trim ring TR-B4
24.125 in (612.78 mm) wide
37.250 in (946.15 mm) tall
5.218 in (132.54 mm) deep
Optional trim ring TR-C4
24.125 in (612.78 mm) wide
45.875 in (1165.23 mm) tall
5.218 in (132.54 mm) deep
Optional trim ring TR-D4
