Appendix B: Canadian Applications

B.1 Standalone Application
JCPU-3030D, with its integral keypad/display, meets Canadian requirements for standalone
applications. Its 640-character, multi-line display complies with ULC requirements for primary
displays.
B.2 Local Network Application
To meet ULC requirements, the network's Manual Controls may only be operated from one
location at any given time.
When panels are networked (using NCM Network Control Modules), employ AKS-1 Key Switch
on each panel's Primary Annunciator to enable its functions. JNCA may be a Primary Annunciator
when AKS-1 is installed. Refer to the JNCA Manual (P/N 51482) for more information.
NOTE: Only one key should be issued for a networked system.
A JNCA or Intelligent Fire Workstation (IFW) may be employed as a Display and Control Center.
In the event that communication fails between the panels and the Control Center, the panels will
continue to function in local/standalone mode.
B.3 Automatic Alarm Signal Silence
If selecting this feature for a system requiring annunciators, consult the Authority Having
Jurisdiction.
B.4 Annunciator Applications
1. In Canada, the ACM series annunciator modules must be used to annunciate the fire alarm
input points/zones only, if no multi-line sequential display is installed.
2. For Canadian applications, the following LED colors must be employed:
– Red must be used to indicate active alarm inputs.
– Yellow must be used to indicate supervisory, burglary or trouble signals.
– Green must be used to indicate the presence of power or an activated output.
B.5 Releasing Devices
Supervision for shorts is required; use REL-47K and type code R
Refer to Section 4.6 "Releasing Applications".
IFC-3030 Installation Manual — P/N 52024:C 08/05/2005
