110
A
A: T
I
M
PPENDIX
ELEPHONE
NSTALLATION AND
AINTENANCE
Figure 9 Wall Mounting a 3102 Telephone
When you mount a 3101, 3101SP, 3102,
or 3103 telephone on a wall, attach the
support bracket and adjust it so that the
bottom of the support bracket rests
against the bottom supports on the
telephone, 1.
Safe wall mounting requires 3/4-inch
drywall and 1.5-inch drywall screws.
1
