Related Manuals for Speco O2P30

Summary of Contents for Speco O2P30

  • Page 1 OWNER’S MANUAL O2P30 Full HD Indoor/Outdoor PTZ IP Camera Please read this manual carefully before operating the unit and retain it for future reference. MODEL O2P30 V1.0...

  • Page 2: Table Of Contents

    Contents Introduction ................... 3 Operation and settings ..............4 Before using the system ..............4 Recommended PC Requirements ...........4 Accessing the unit .................5 Web Viewer Overview .................6 Configuration menu overview ..........9 Configuring the Device ...............9 Accessing the Configuration menu .........9 System settings ..............10 Audio &...

  • Page 3: Introduction

    Introduction This Speco IP Camera is designed for use on an Ethernet network and must be assigned an IP address to make it accessible. This manual contains instructions on how to install and manage the Speco IP Camera in your networking environment. Some knowledge of networking environments is recommended.

  • Page 4: Operation And Settings

    ActiveX controls. If you find this message “This website wants to install the following add-on: ‘IPCam_Streamer.cab’ from ‘Speco Technologies’ , Click ‘allow’ to enable live video in the web Web Browser Microsoft Internet Explorer (32 bit) 7/8/9 viewer.

  • Page 5: Accessing The Unit

    Accessing the unit Click the [OK] button and then the web viewer is displayed in your browser. You can access the Speco IP device by following the below steps. Note: • You can also access the web viewer as shown below.

  • Page 6: Web Viewer Overview

    Web Viewer Overview Displays Video Codec, Resolution and FPS of the selected video stream. Network connection type (TCP or UDP). If checked, the client connects to the server using TCP connection. Select buffering time of live stream. Click to display the check box of [Hostname], [Framerate] and [Bitrate] options.
  • Page 7 Provides all the necessary tools Click to expand and then check the [Edge for setting up the device to your Enhancement] option. The user gets a requirements. The user will need more sharp reception on the live view administrator level to do this. window.
  • Page 8 1. Click this button to open the folder Click this button to switch the sound off browse window for local recording and on, for the speaker of the computer. on the PC. After the folder selection, (Color icon: On, Gray scale icon: Off.) video is recorded automatically without selection of the folder when the button is clicked again.

  • Page 9: Configuration Menu Overview

    Configuring the Speco IP Camera Device Audio Setup Audio & Video PTZ Config The features and options of the Speco IP device are configured Preset Setup through the Setup menu. Auto Tracking Only administrator-level users have permission to access the Setup Basic Setup menu.

  • Page 10: System Settings

    System settings > Synchronize with an Internet Time Server: Select if you want to synchronize the IP device’s date and time with an NTP (Network Time Protocol) server. Specify the NTP server’s Current Version name. Click the [Test] button for connection test to the Displays the current Model Name and Software version.
  • Page 11 Upgrade & Reset Note: Backup and Restore are intended for use on an IP device having the same version of firmware. This feature is not intended for multi-configurations or for firmware upgrades. Firmware > Upgrade 1. Click the [Browse] button. 2.
  • Page 12 Storage Note: • The recorded file name is made automatically as the “[Created date of the file]_[GMT Recording Time].AVI” type. • Recorded file on the SD card, is recording 1 frame per second when set video codec to MJPEG. Device Management >...
  • Page 13 > Remove the micro SD card Click the [Search] button and then the search result is displayed on the list. 1. Click the [Unmount] button. If the micro SD card is unmounted from the system correctly, the [Unmount] > Download: You can download the recorded data of the list button will be changed to the [Mount] button.
  • Page 14 Text Overlay Status Report Text Overlay Log & Report status > Enable: Set to ON or OFF. Setup menu appears when ON. The System log provides a summary of the status of the IP device. The unit records the data of the software activity in a file. >...

  • Page 15: Audio & Video Settings

    Audio & Video settings between 30 and 25. • Save: Click this button to confirm the settings. Video Setup • Default: Click this button to restore back to original factory settings. Preview Focus 1. Move the camera to the point you want by using the arrow buttons.
  • Page 16 the zoom, the focus is set automatically and then the Exposure focus mode automatically changes back to manual mode. Manual: Focus is set automatically after zoom movement is finished. > Focus Distance: Selects the minimum shooting distance for the focus. Select [Focus Distance] option on the [Focus] menu, then select a focus distance value.
  • Page 17 > WDR/BLC: Use WDR/BLC option to view the object clearly White Balance in backlight conditions. Select [WDR/BLC] option on the [Exposure] menu. WDR: WDR (Wide dynamic range) feature can be very helpful to cope with very challenging lighting conditions. It is capable of capturing both of the dark part and bright part and combining the differences into a scene to generate a highly realistic image as the original scene.
  • Page 18 ONE PUSH: If you select the [ONE PUSH] mode, you will Day/Night be able to set up the White Balance automatically. > Color Temp: Click to select the option. Indoor: The color temperature range for the proper white balance is approximately 3200 K. Outdoor: The color temperature range for the proper white balance is approximately 5100 K.
  • Page 19 Privacy Mask LEVEL and adjust the transparency of MASK. > Height: Increase or decrease the vertical size of the mask. > Width: Increase or decrease the horizontal size of the mask. > Move Y: Moves vertical position of the mask. >...
  • Page 20 Special > Sharpness: The degree to which the boundary of the two portions is clearly distinguished. Adjust the value by using a jog controller or enter the desired value. If you set the sharpness value to higher, the image outline becomes sharp. If you set to lower value, the image outline becomes dim.
  • Page 21 Basic Setup > Stream quality: If the [Quality] option set to VBR, this option is displayed. Select the stream quality from the drop down box, the camera supports five types. (Highest, High, Medium, Low and Lowest) > Alias: Enter the profile name you want to use. >...
  • Page 22 Region Of Interest 2. Click the edge or corner of the window box to adjust the window size. 3. Click the [Save] button to save the settings. Note: ROI areas can not overlap with each other. You can set and streaming the desired area on the live view window to use ROI(Region Of Interest) function.
  • Page 23 Audio Setup PTZ Config Allows the user to configure different PTZ controls by using different PTZ protocols. Audio In > Enable: Click the check box if you want to send the audio from the microphone input connector. Note: The Clients connected to the IP device remain unaffected PTZ configuration with additional changes made in the setting.
  • Page 24 automatic return to a particular mode. Preset Off: Not in use. Last Tour: After the Auto Return Time is over, the camera restarts the previous tour. Home: When the touring is stopped, returns to the camera’s basic position after the set time. Note: You have to set the basic position to perform this function.
  • Page 25 > To register preset position 4. Repeat the steps 2 to 3 to add other preset index number. You can set the preset index number up to 8 for 1. Enter the preset number you wish to register. the one group. 2.
  • Page 26 > To play the auto pan Auto tracking 1. Click the [Play] button to start the Auto Pan function. 2. Click the [Stop] button to stop the Auto Pan function. Note: If you click the [CLEAR] button, all of Auto pan position will be deleted.

  • Page 27: Network Settings

    Main configuration • Default: Click this button to restore back to original factory settings. > Track Mode: During perform the Auto Tracking, track the object using PT(Pan / Tilt) or PTZ(Pan / Tilt / Zoom). Network settings > Target Size SMALL: Make images about 1/4 of the object using Basic Zoom feature.
  • Page 28 connected status of router. Multicast > External IP: When you connect a router that supports UPnP RTP (Real-time Transport Protocol) is an internet protocol that allows function, this option is displayed. Displays the external IP programs to manage the real-time transmission of multimedia data, address allocated router.
  • Page 29 Note: IP Address Setup Each profile using multicast needs its own multicast IP address and port numbers to avoid address conflict. When more than 2 profiles use same multicast IP address, each [Base RTP port] number should be distinguished from the other port number more than 6 at least. Multicast >...
  • Page 30 Gateway: Enter the gateway address. IP filtering DNS server status The access of the IP addresses in the list are allowed or denied according to the choice made in the drop-down list of the Basic > Primary DNS server: Enter the Primary domain name server policy option.
  • Page 31 Deny all: Deny all the IP address basically, but the IP • Remove: Click this button to delete the IPv6 address. addresses in the list are allowed. At least one IP address 1. Select the alias from the list. is required to activate this function. 2.
  • Page 32 SNMP The Simple Network Management Protocol (SNMP) is an application You can specify network Quality of Service (QoS) settings. protocol to exchange the management information of network devices. QoS DSCP Configuration SNMP v1/v2c > Video DSCP: Enter the priority of Video for DSCP >...
  • Page 33 802.1x > EAPOL Version: Select the EAPOL version. Specifies whether 802.1x network access is enabled. > EAP ID: Enter the ID of the client certificate using up to 16 characters. > Password: Enter the password of the client private key using up to 16 characters.

  • Page 34: User Settings

    User settings Note: • When you set the [Enable] option ON, [Enable anonymous login] option is enabled automatically. Basic • You should set the SIP port number so that it does not conflict The IP device is shipped with the login rights of administrator only. with multicast port and 5353.
  • Page 35 4. Select the authority from the drop down list to provide Anonymous the access rights to each user and then click the [Save] > Enable anonymous login to confirm your selection. Check the box to enable anonymous user login - allows the Administrator: Allows you to operate setup menus user access for only viewing the live stream image.

  • Page 36: Event Settings

    Event settings User ID: Type the user name for the Folder shared in the FTP server. Password: Type the password for the folder shared in Email & FTP the FTP Server. Event Servers are used to receive the recorded video clip and/or Folder: Type the path with the folder that is shared in notification messages.
  • Page 37 Address: Enter the SMTP server address. Sensor & Relay Port: Enter the port number. The default port is 25. Enable SSL: Check when use the SSL (Secure Socket Layer) protocol. SSL protocol is cryptographic protocols that provide secure communication on a network.
  • Page 38 Motion detection How to set the motion detect window 1. Click the [Add] button. The motion detect window is displayed. You can add five windows maximum for the motion detection area. 2. Set the [Sensitivity] option. 3. Click the edge or corner of the window box to adjust the window size for motion detection.
  • Page 39 Triggered Event deactivated. When an event (VA/ Motion detect/ Sensor Event) occurs, this unit SDCard recording: Record on the SD card when records the live images and routes as configured. the event runs. FTP server(JPEG): Sends the JPEG Image to the FTP server.
  • Page 40 Scheduled Event to FTP(JPEG) is checked, FTP(JPEG) is always enabled regardless of the activation time. • Save: Click this button to confirm the settings. Activation Time > Always : You can use always by using the FTP server regardless of activation time. >...
  • Page 41 Operation and settings...

  • Page 42: Reference

    Reference Troubleshooting This section provides useful information to help you to resolve any difficulty you might have with your Speco IP device. Fault symptoms, possible causes and remedial actions are provided here. IP Setting problems • ARP/Ping: Disconnect and reconnect the power to the network camera. The device should get the IP within 2 minutes.
  • Page 43 Accessing camera external to the local network • Firewall Protection: Check for the internet firewall with the system administrator, either he has to do port forwarding or modify the DMZ function on the router. • Default router needed: Check if you need configure the router settings. Sporadic network performance •...
  • Page 44 • If we obtain lower frame rate than set we need to check from the system administrator for sufficient bandwidth available or reduce the number of applications running on the client computer. • If the client PC’s are unable to access the multicast stream, check with the system administrator for the use of a valid multicast address or check if the router is supporting multicasting.
  • Page 45 It is required to use a power source of either AC 24 V or PoE+. • PoE connection must use PoE+. (PoE+(IEEE 802. at-2009) : PoE+ provides up to 25.5 W of Power. For all further support please contact Speco Technologies technical support. Reference...

  • Page 46: Specifications

    Specifications Item O2P30 Image Sensor 6.49 mm (1/2.8” type) CMOS Lens x30 Zoom, f = 4.3 mm to 129 mm Maximum Resolution 1920 x 1080 Day&Night ICR Day & Night (Day / Night / Auto) Mininum Color 1.0 lux (F1.6, Sens-up off ), 0.02 lux (F1.6, Sens-up x64) Illumination 0.1 lux (F1.6, Sens-up off ), 0.0008 lux (F1.6, Sens-up x64)
  • Page 47 Sample Rate 8 KHz Audio Bit Rate G.711: 64 kbps, G.726: 24 kbps, 32 kbps Ethernet 10/100 Ethernet Protocol IPv4 and IPv6 TCP/IP, UDP, HTTP, HTTPS, RTP, RTSP, DHCP, ICMP IPv4 FTP, SMTP, NTP, ARP, SNMP v1/v2c/v3, DDNS ONVIF Profile S Pan/Tilt Travel Range Pan: 360˚(Endless), Tilt: 180˚...
  • Page 48 Misc. Mount Accessory O2PWB (wall mount bracket, sold separately) Material Aluminum, Plastic sunshield Rated Power PoE+ / AC 24 V (25 W) Waterproof IP66, IK10 Always ON Operation Temperature -4˚F to 122˚F Weight 7.3 lbs Dimension (Ø x H) 7.67” x 9.0” Reference...
