  • Page 1 Quick Start Guide 2MP 4X PTZ IP Camera O2P4X Version 1.0.1...
  • Page 2: Table Of Contents

    Table of Contents DEVICE CHECK ......................1 Check Accessories ........................... 1 Check Device ............................1 Installation Template ..........................1 SD Card Slot and Reset Button ........................ 2 DEVICE INSTALLATION ....................3 Component Installation .......................... 3 Installation Steps ............................ 4 2.2.1 Installation Environment ........................
  • Page 3 Thank you for purchasing this Network camera! This manual is designed to be a reference tool for your system. Please read this manual carefully before operating the unit and retain it for future reference. Should you require any technical assistance, please contact Speco Technologies Technical Support.
  • Page 4 Important Safeguards and Warnings 1. . . . Electrical safety All installation and operation here should conform to local electrical safety codes. Use a certified/listed 12VDC Class 2 power supply only. Please note: Do not connect two power supplying sources to the device at the same time; it may result in device damage! The product must be grounded to reduce the risk of electric shock.
  • Page 5 Before installation, check the package and make sure that all components are included. Keep the package material in case the camera needs to be sent back for service or repair. Contact your rep or Speco customer service department immediately if something is broken or missing in the package.
  • Page 6: Device Check

    1 Device Check Check Accessories Before installation, check the package and make sure that all components are included. Contact your rep or Speco customer service department immediately if something is broken or missing in the package. Accessory Name Amount Network Camera Unit...
  • Page 7: Sd Card Slot And Reset Button

    Figure 1-2 1.4 SD Card Slot and Reset Button SD card slot and button are shown in Figure 1-3. Please make sure the SD card is in a non read-write state when removing it. Otherwise, it may result in data loss and SD card damage. The button is used for setting the device back to a factory default state.
  • Page 8: Device Installation

    2 Device Installation Component Installation The installation of pedestal seal ring is shown in Figure 2-1. Figure 2-1 The installation setup is shown in Figure 2-2. Figure 2-2...
  • Page 9: Installation Steps

    2.2 Installation Steps 2.2.1 Installation Environment The ceiling mount speed dome can be installed on a hard surface ceiling in an indoor environment. Before the installation, please make sure: The ceiling is thick enough to install the expansion bolt. The ceiling can sustain at least 8x the weight of the speed dome. 2.2.2 Installation Steps Step 1 Install the default pedestal seal ring as shown in Figure 2-1.
  • Page 10: Ip Scanner

    3 IP Scanner Overview IP Scanner can search for the device on the local network. search for the device on the local network. Please note that only devices that are on the same subnet can be discovered. Please note that only devices that are on the same subnet can be discovered. 3.2 Operation Open up IP Scanner.
  • Page 11: Web Operation

    4 Web Operation This device supports viewing and management via a web browser on a PC. This device supports viewing and management via a web browser on a PC. Login and Main Interface Login and Main Interface Open the browser and input network camera address in the address bar or double click the Open the browser and input network camera address in the address bar or double click the Open the browser and input network camera address in the address bar or double click the device in IP Scanner.
  • Page 12: Appendix Surge Protection

    5 APPENDIX Ⅰ Ⅰ Ⅰ Ⅰ Surge Protection This device uses TVS lighting protection technology. It can effectively prevent damages from various pulse signals below 2000W, such as sudden lighting and surge. While maintaining your local electrical safety code, you still need to take necessary precaution measures when installing the speed dome in an outdoor environment.
  • Page 13: Appendix 1 2V Dc Wire Gauge And Transmission Distance Reference

    6 APPENDIX Ⅱ Ⅱ Ⅱ Ⅱ 12V DC Wire Gauge and Transmission Distance Reference The recommended max transmission distance is under the following environments: The wire diameter is fixed and the DC 12V power voltage loss rate is below 10%. For the device being supplied the DC power, the max allowed voltage loss rate is 10%.
  • Page 14: Appendix Ⅲ Ⅲ Ⅲ Ⅲ Wire Gauge Reference

    7 APPENDIX Ⅲ Ⅲ Ⅲ Ⅲ Wire Gauge Reference Metric bare wire Bare wire cross diameter section ( ) ( ) 0.050 0.00196 0.060 0.00283 0.070 0.00385 0.080 0.00503 0.090 0.00636 0.100 0.00785 0.110 0.00950 0.130 0.01327 0.140 0.01539 0.160 0.02011 0.180 0.02545...
