- Page 1 OWNER’S MANUAL Full HD IP Camera Please read this manual carefully before operating the unit and retain it for future reference. MODELS O2D10 O2DP14 O2B16 V1.0...
-
Page 2: Table Of Contents
Contents Introduction ................... 3 Operation and settings ..............4 Before using the system ..............4 Recommended PC Requirements ...........4 Accessing the Unit ................5 Web Viewer Overview .................6 Configuration menu overview ..........7 Configuring the Network Camera ...........7 Accessing the Configuration menu .........7 System settings ...............8 Audio &... -
Page 3: Introduction
Introduction This Speco IP Camera is designed for use on an Ethernet network and must be assigned an IP address to make it accessible. This manual contains instructions on how to install and manage the Speco IP Camera in your networking environment. Some knowledge of networking environments is recommended. -
Page 4: Operation And Settings
ActiveX controls. If you find this message “This website wants to install the following add-on: ‘IPCam_Streamer.cab’ from ‘Speco Technologies’ , Click ‘allow’ to enable live video in the web Web Browser Microsoft Internet Explorer (32 bit) 7/8/9. -
Page 5: Accessing The Unit
Accessing the Unit Logging in to the Web Viewer Run IP Scanner and locate the Speco IP device. You can access the Speco IP device by following the below steps. When IP devices appear in the window, double-click Launch IP Scanner the IP address to open up the browser and start the web viewer. -
Page 6: Web Viewer Overview
Web Viewer Overview Click to expand and then check the [Edge Enhancement] option. The user gets a more sharp reception on the live view window. Note: This feature only affects the live view window. Click to save the current image in JPEG format on your computer. -
Page 7: Configuration Menu Overview
Configuring the Speco IP Camera Device (Color icon: On, Gray scale icon: Off.) Click this button to switch the sound off The features and options of the Speco IP device are configured and on, for the speaker of the computer. through the Setup menu. -
Page 8: System Settings
System settings Upgrade & Reset Current Version Displays the current Model Name, Software, ISP and MCU version. System Restart Click the [Confirm] button to restart the IP device. It takes a couple of minutes for the IP device to restart. Backup &... - Page 9 Storage > Remove the micro SD card 1. Click the [Unmount] button. If the micro SD card is unmounted from the system correctly, the [Unmount] button will be changed to the [Mount] button. Remove the micro SD card from the micro SD card slot of the camera.
- Page 10 Text Overlay > Multi-Line Text: Enter characters in the text field. Maximum number of input characters depends on the resolution. Font Size Column > Color: You can make any color by adjusting R.G.B LEVEL. > Size: You can adjust the font size. >...
-
Page 11: Audio & Video Settings
Status Report Audio & Video settings Video Setup Preview 1. Move the camera to the point you want by using the arrow buttons. 2. Adjust the zoom, focus options. 3. Set the Pan, Tilt, Zoom or Focus step options. (O2B16 does not support the PAN and TILT functions.) Note: Log &... - Page 12 > Sensor Framerate: Select the Sensor Framerate value. Focus Note: • FPS maximum value cannot exceed the value of Sensor Framerate. • Pivot, Video out, WDR, Max Stream Count are limited, depending on the Install Preset setting. • You need to reset the Motion Detect and Smart Analytics in the Event menu every time Pivot Mode is selected or deselected.
- Page 13 Exposure 1/10 000 1/5 000 1/2 500 1/1 500 1/1 000 1/700 1/500 1/480 1/400 1/360 1/300 1/250 1/240 1/180 1/150 Maximum Shutter 1/120 1/100 1/60 1/50 1/30 1/25 1/20 1/15 > Anti Flicker: Remove the band noise caused by fluorescent light.
- Page 14 White Balance Day/Night > Mode: Under the [Mode] option in the [White Balance] menu, select the following mode. Auto: Adjust the white balance of the full image area. > Mode: Under the [Mode] option in the [Day/Night] menu, Use this function in the environment by special lighting select the following mode.
- Page 15 Note: SmartIR • If the difference of value between the [Day >> Night] and [Night >> Day] is not big enough, there may be a problem to convert between the Day and Night modes. • When the [AGC] set to [Off ], the [Day/Night] is initialized to the [Day] mode.
- Page 16 Basic Setup Image Profile Select the stream [Profile1], [Profile2], [Profile3] or [Profile4] depending on the Install Preset. Note: It is displayed the constraints according to the current preset settings by mouse-over at the right-top of the current Preset. Profile Profile1 Profile2 Profile3 Profile4...
- Page 17 Audio Setup constant bit rate. > Smart Codec: You can improve the image of a specific area to configure the Region or Face Detection. If you select the [Region] option, the [Smart Codec (Region)] window is activated. Note : • When the video codec is H.264 or H.264_HIGH, the Smart Codec can be selected.
-
Page 18: Network Settings
Network settings Multicast RTP (Real-time Transport Protocol) is an internet protocol that allows programs to manage the real-time transmission of multimedia data, Basic via unicast or multicast. General Profile > MAC address: Displays the MAC address. > RTP unicast: When enabled the transmission of the data to Port &... - Page 19 TCP/IP IP filtering The access of the IP addresses in the list are allowed or denied according to the choice made in the drop-down list of the Basic policy option. The administrator can add up to 10 IP address entries to the list (a single entry can contain multiple IP addresses).
- Page 20 SNMP The Simple Network Management Protocol (SNMP) is an application You can specify network Quality of Service (QoS) settings. protocol to exchange the management information of network devices. QoS DSCP Configuration > Video DSCP: Enter the priority of Video for DSCP SNMP v1/v2c (Differentiated Service Code Point) Quality of Service.
-
Page 21: User Settings
User settings > Delete the registered user 1. Choose the user ID you want to delete. Basic 2. Click the [Remove] button. The IP device is shipped with the login rights of administrator only. Note: If others need to access the IP device excluding the configuration a The default administrator user ID ‘admin’... -
Page 22: Event Settings
Event settings network. Receiving address: Type the recipients e-mail address. You can specify only one recipient e-mail Email & FTP address. Event Servers are used to receive the recorded video clip and/or Administrator address: Type the e-mail address of notification messages. the administrator. - Page 23 Motion Detection Audio detection Audio Detection > Enable: Set to [ON] or [OFF]. The Basic Configuration menu is displayed when set to [ON]. Basic Configuration Preview > Level: Select the level of audio detection from the You can preview the motion detection window on the preview drop-down list.
- Page 24 Triggered Event 3. Click the left mouse button on the screen to set the detection area. When an event (Anaytics/ Motion detect/ Sensor Event/Audio Intrusion: When the perceived object moves into the detect) occurs, this unit records the live images and routes as event area, the Intrusion Event is activated.
- Page 25 Scheduled Event Activation Time > Always : You can use always by using the FTP server regardless of activation time. > Only scheduled time: Continuously record according to the set time and the selected weekday. Drag and drop with left button of the mouse to set the channel and time you want to record.
-
Page 26: Reference
Reference Troubleshooting This section provides useful information to help you to resolve any difficulty you might have with your Speco IP device. Fault symptoms, possible causes and remedial actions are provided here. IP Setting problems • ARP/Ping: Disconnect and reconnect the power to the network camera. The device should get the IP within 2 minutes. - Page 27 • If the client PC’s are unable to access the multicast stream, check with the system administrator for the use of a valid multicast address or check if the router is supporting multicasting. • If the images appear to have white of gray stripes on it, upgrade the Video graphics driver on the client PC to the latest version. •...
-
Page 28: Specifications
Specifications Item O2D10 O2DP14 Image Device 6.4 mm (1/2.8” Type) CMOS Lens Type 3 mm to 9 mm F1.2 (3x Zoom) Day / Night ICR (Auto / Day / Night / External / Schedule) Color: 0.03 lux @ F1.2 (1/30 sec, 50 IRE) - Page 29 Item O2B16 Image Device 6.4 mm (1/2.8” Type) CMOS Lens Type 3 mm to 9 mm F1.2 (3x Zoom) Day / Night ICR (Auto / Day / Night / External / Schedule) Color: 0.03 lux @ F1.2 (1/30 sec, 50 IRE) Minimum Illumination Camera B/W: 0 lux @ IR LED on...
