Component
Microphone jack
Headphone jack

Back

Your computer includes the following components (your computer may differ from the computer shown
below).
Audio in speaker jack
Center/subwoofer jack
Ethernet (network) jack
Component
Power connector
www.gateway.com
Icon Description
Plug a microphone into this jack. This jack is color-coded red or pink.
Plug powered, analog front speakers, an external amplifier, or headphones
into this jack. This jack is color-coded green.
Power connector
Voltage switch
Case cover
thumbscrew
(optional)
Cover release lever
Parallel port
PS/2 keyboard port
IEEE 1394 port
(optional)
Case cover
thumbscrew
Icon Description
Plug the power cord into this connector.
Headphone jack
Microphone jack
Optical out jack (optional)
Rear speaker jack (optional)
Serial port
Video port
PS/2 mouse port
USB ports
PCI card slots (behind EMI shields)
