OUTPUT TO ASSISTIVE LISTENING DEVICE (ALD)

1. Turn the Audio (ALD) Out volume control on
the REDCAT side panel all way the down.
2. Determine the size and type of audio input
jack on the device as many manufacturers'
products differ in connector size and shape.
The Lightspeed LES-370 Personal FM System
requires a 3.5mm to 3.5mm patch cable (part#
MSC3535, not included).
3. Connect a patch cable from the ALD's
microphone jack or AUX input to the 3.5mm
audio jack labeled "AUDIO OUT" on the side
of the REDCAT.
4. Adjust the volume control on the ALD's
receiver to maximum output. NOTE: This is to
set the maximum allowable signal from
the REDCAT.
5. With the REDCAT and ALD turned on,
speak into the REDMIKE and slowly adjust
the AUDIO OUT volume control until the
appropriate audio level is attained in the ALD's
receiver headphones.
41
