OPTIONAL REDMIKE VC CONTROLS
1. POWER/MUTE BUTTON
2. POWER/LOW BATTERY INDICATOR: A
BLUE light indicates the REDMIKE VC is on
and fully charged. A RED light indicates a
charge is needed.
3. Battery Compartment: To open, slide the
door downward. The battery should only be
replaced by a Lightspeed AA rechargeable
sensing battery
(part # NH2A27).
4. YELLOW PROTECTIVE TAB: Slide the
battery compartment door and remove this
disposable protective tab before use.
CONT'D
5. AUDIO/MICROPHONE INPUT: Use this
input to plug in a laptop, MP3 player or other
audio source to wirelessly transmit audio to be
played through the system. Alternatively, an
external microphone can be connected.
6. CHANNEL SELECT SWITCH (CH A/B): Use
this to choose Channel A or B. If you are using
a single microphone, we recommend using
Channel A.
7. Volume controls (up - down)
8. Charger Contacts (+ -): These contacts
interface with the charging tabs when the
REDMIKE VC is placed in the BC-RMCC cradle
charger.
