REDMIKE CONTROLS AND CONNECTIONS
1. POWER BUTTON: Press this button to turn
the REDMIKE ON, press again to turn it OFF
(mute).
2. POWER/LOW BATTERY INDICATOR: A
BLUE light indicates the REDMIKE is on and
fully charged. A RED light indicates a charge is
needed.
3. Battery Compartment: To access the battery
compartment, slide the door downward.
The battery should only be replaced by a
Lightspeed AA rechargeable sensing battery
(part # NH2A27).
18
4. YELLOW PROTECTIVE TAB: Slide the
battery compartment door open to remove
this disposable protective tab before use.
NOTE: do not attempt to remove the tab
without first opening the compartment door,
as it may tear, leaving fragments.
Note: REDMIKE microphones are shipped
with batteries installed. Charge the
microphone overnight before using.
