Rear Panel; Dvr Rear Panel - Optiview VR LT Quick Start Up Manual

Record REC
Remote control
ACT
indication light
Status
Status
indication light
Power
Power
indication light
Record light 1-16
IR Receiver IR
CD-ROM button

1.7 Rear Panel

1.7.1

DVR Rear Panel

4/8CH LT series rear panel
1
2
3
4
5
6
7
8
9
10
16CH LT series rear panel
1
2
3
4
5
6
7
8
9
10
11
12
Manually stop/start recording, working with direction keys
Or numeral keys to select the recording channel.
Remote control indication light
If there is Fn indication light, current status indication light is null.
Power indication light
System is recording or not. It becomes on when system is recording.
It is to receive the signal from the remote control.
Pop-up or insert the CD.
4-8CH VR LT Series
Video input
Audio input
Video CVBS output
Audio output
Network port
USB port
Video VGA output
Power input port
Alarm input/alarm output/RS485 port
Power button
VR16LT Rear Panel
Video input
Audio input
Video CVBS output
Audio output
Network port
USB port
HDMI port
RS232 port
Video VGA output
Alarm input/alarm output/RS485 port
Power input port
Power button
8
