Electric Installation

2.3
2.3 Electric Installation
®
This subsection describes how to connect the 2N Helios IP Audio Kit into your Local
Area Network (LAN) and how to connect supply voltage and other electric interfaces.

Device and PCB Connectors

®
Figs. 2.1 and 2.2 show the layout of the 2N Helios IP Audio Kit connectors and
terminals.
®
Figure 2.1 2N Helios IP Audio Kit Connectors
®
Figure 2.2 2N Helios IP Audio Kit PCB Connectors
