1.1 Product Description

Basic Features

®
2N Helios IP Audio Kit is a universal and reliable IP intercom module designed for
integration in the third parties' equipment. It is provided with a number of useful
functions that are not quite common in the devices of this category. Featuring the SIP
standard support and compatibility with renowned IP exchange and telephone
manufacturers, 2N
the market.
®
2N Helios IP Audio Kit is equipped with a 10W power amplifier for external
loudspeaker connection. If the power output of the internal loudspeaker is insufficient
for your specific application, you can connect an external loudspeaker to the line
output. You can also connect an external electret microphone or another audio signal
source to the IP intercom line output.
®
2N Helios IP Audio Kit allows up to 16 separate buttons or a 16-button matrix
keypad to be connected. Set the button function flexibly according to your specific
application needs. You can set up to three telephone numbers and call time profiles to
each of the buttons to make the called subscriber accessible any time. Configure the
buttons as a numerical keypad, which can be used as a switch activation code lock or
for dialling a preset or any other telephone number.
®
2N Helios IP Audio Kit is equipped with one relay output and two active 12V
outputs. Use the numerical keypad or, during the call, any telephone to control these
outputs. A wide range of output mode settings help you make use of a high number of
applications.
®
2N Helios IP Audio Kit is equipped with two galvanically isolated digital inputs and
three status signalling outputs.
®
2N Helios IP Audio Kit is very easy to install. All you have to do is connect it to
your LAN using the LAN cable. An integrated two-port LAN switch simplifies installation
on sites with a limited LAN infrastructure. Supply the intercom either from a 9-36V
source or directly from your POE supporting LAN.
Use a PC web browser to configure your 2N
®
2N Helios IP Manager to administer extensive intercom installations easily and
quickly.
®
Helios IP Audio Kit can make use of all VoIP services available on
Product Description
®
Helios IP Audio Kit. Apply the
