Winnebago Solei User Manual
  1. Manuals
  2. Brands
  3. Winnebago Manuals
  4. Motorhomes
  5. Solei
  6. User manual

Winnebago Solei User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Rev. 1512150219
Part No. 161500-15-026
Copyright 2014 Winnebago Industries, Inc. All rights reserved.

Advertisement

Table of Contents
loading

Related Manuals for Winnebago Solei

Summary of Contents for Winnebago Solei

  • Page 1 Rev. 1512150219 Part No. 161500-15-026 Copyright 2014 Winnebago Industries, Inc. All rights reserved.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1 – INTRODUCTION About this Manual ..........................1-1 Safety Messages Used in this Manual ....................1-1 Pre-Delivery Inspection ........................1-2 Front Axle Tire Alignment ....................... 1-2 Service and Assistance ........................1-2 Reporting Safety Defects ........................1-2 Occupant and Cargo Carrying Capacity Label ................. 1-3 Vehicle Certification Label .......................
  • Page 4 Table Of Contents Front Drop-Down Shade (12-Volt) ....................3-7 Radio In-Dash/Rearview Monitor System ..................3-7 Radio In-Dash/Rearview Monitor System ..................3-9 CB Radio Power Wiring ......................... 3-11 Parking Brake ..........................3-11 Exhaust Restriction Braking System ....................3-11 Hazard Warning Flashers ........................ 3-12 Signal Lever/Headlight High-Low Beam ..................
  • Page 5 Table Of Contents Washer/Dryer – Stackable ......................4-10 Washer/Dryer (Model 38R) ......................4-11 Washer/Dryer – Prep Package ......................4-12 5 – PROPANE GAS Propane Gas Supply .......................... 5-1 Safe Use of the Propane Gas System ....................5-2 Propane Gas Warnings and Precautions ................... 5-3 Propane Gas Pressure Regulator .......................
  • Page 6 Table Of Contents Front TV Ignition Switch Interlock ....................8-2 TV Antenna – Digital ........................8-2 TV Signal Amplifier ......................... 8-3 Cable TV and Satellite Connections ....................8-3 TV Digital Satellite System Wiring ....................8-4 TV Digital Satellite System – Automatic ..................8-4 Exterior Entertainment Center (Adjustable) ..................
  • Page 7 Table Of Contents Cabinetry – Cleaning ........................11-7 Decorative Vinyl Wall Paneling – Cleaning ................... 11-7 Solid Surface Countertop – Corian® ....................11-7 Tables and Countertops ........................11-8 Stainless Steel Appliances ......................11-8 Galley Sink ............................. 11-9 Range and Refrigerator ........................11-9 Vinyl Flooring ..........................

  • Page 9: Introduction

    The instructions included in this manual are intended as a guide, and in no way DANGER indicates a hazardous situation extend the responsibilities of Winnebago which, if not avoided, will result in death or Industries beyond the standard written serious personal injury.

  • Page 10: Pre-Delivery Inspection

    National Highway Traffic Safety Administration delivery inspection of the chassis and all (NHTSA) in addition to notifying Winnebago motorhome components. Industries, Inc. As a part of the pre-delivery inspection...

  • Page 11: Occupant And Cargo Carrying Capacity Label

    SECTION 1 – INTRODUCTION or go to their website at http://www.safercar.gov or write to: Administrator, NHTSA 1200 New Jersey Avenue S.E. Washington, D.C. 20590 You can also obtain other information about motor vehicle safety from the NHTSA website at http://www.safercar.gov OCCUPANT AND CARGO CARRYING CAPACITY LABEL This label is affixed in the driver’s area next to...

  • Page 12: Vehicle Certification Label

    These pressure levels must be maintained to assure proper handling, safety, 2. Chassis manufacture date. and fuel economy. 3. Month and year of manufacture at Winnebago ® 9. Rear Axle Wheel Configuration: Single or Industries Dual as it relates to the inflation.

  • Page 13: Specifications And Capacities

    90 gal. Notes: All information is based upon the most recent data available. Visit the Winnebago Industries, Inc. web page – www.winnebagoind.com – for the most current product information. The height of each model is measured to the top of the tallest standard feature and is based on the curb weight of a typically equipped unit.

  • Page 14: Owner And Vehicle Information

    Motorhome Serial Number ___________________________________________________________ Chassis Vehicle Identification No. (VIN) ________________________________________________ Vehicle Mileage at Delivery __________________________________________________________ Selling Dealer Name ________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ ® YOUR WINNEBAGO INDUSTRIES DEALER /SERVICE CENTER Name ____________________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ Contact ____________________________________________Phone ________________________ CHASSIS SERVICE CENTER...

  • Page 15: Safety And Precautions

    SECTION 2 – SAFETY AND PRECAUTIONS GENERAL WARNINGS DRIVING SAFETY • Only seats equipped with seat belts are to be occupied while the vehicle is moving. WARNING • Make sure all passengers have seat belts fastened. Lap belts should fit low on the hips and upper thighs.

  • Page 16: Fuel And Propane Gas

    SECTION 2 – SAFETY AND PRECAUTIONS • Do not operate the cruise control on icy or extremely wet roads, winding roads, in heavy WARNING traffic, or in any other traffic situation where a constant speed cannot be maintained. • Use care when accelerating or decelerating on Propane gas containers, gasoline, or a slippery surface.

  • Page 17: Propane Gas Leaks

    SECTION 2 – SAFETY AND PRECAUTIONS DA NG E R DA NG E R Do not use gas cooking appliances for IF YOU SMELL PROPANE comfort heating. Can lead to carbon 1. Extinguish any open flames and all monoxide poisoning, which can lead to smoking materials.

  • Page 18: Carbon Monoxide Warning

    RV application. We area. recommend obtaining a replacement from your ® Winnebago Industries dealer. CARBON MONOXIDE ALARM Further Information Your coach is equipped with a Carbon See the manufacturer’s user guide provided in...

  • Page 19: Smoke Alarm

    RV application. We injury. recommend obtaining a replacement from your ® Winnebago Industries dealer. Replacement Further Information When replacing this alarm, we recommend replacing only with the same model, or with one Please read the information provided by the that is also listed for RV application.

  • Page 20: Fire Extinguisher

    Extinguisher, the replacement must be the same near the entrance door. type and size as the one originally supplied in your coach. We recommend obtaining a replacement only from your Winnebago ® Industries dealer or a reliable RV parts supplier.

  • Page 21: Maintenance

    SECTION 2 – SAFETY AND PRECAUTIONS • Never load the motorhome in excess of the gross vehicle weight rating or the gross axle weight rating for either axle. MAINTENANCE • Do not remove the radiator cap while engine Escape Window and radiator are still hot.

  • Page 22: Power Sofas And Beds

    SECTION 2 – SAFETY AND PRECAUTIONS Most slider windows along the side of any motorhome can also be used as alternate emergency exits, should the need arise. WARNING To use slider windows as an exit: • Lift window latch UP. Keep all persons clear of the slideout •...

  • Page 23: Mold, Moisture, And Your Motorhome

    ® Winnebago Industries throughout the outdoor and indoor air. Because If Winnebago Industries determines that mold of the nature of the use of a motorhome, it is ® ® is present in the Winnebago...

  • Page 24: Roof

    However, if an proper towing equipment to use. emergency requires you to change the tire ® Winnebago Industries does not assume yourself, please exercise extreme caution and responsibility for damage incurred while towing read all tire changing information in the chassis this vehicle.

  • Page 25: Jump Starting

    SECTION 2 – SAFETY AND PRECAUTIONS WARNING Stay out from beneath the motorhome while it is suspended by the towing assembly. Do not allow passengers to occupy a towed vehicle. Death or serious injury can result. JUMP STARTING If your coach will not start from the chassis battery, try using the Battery Boost switch to divert power from the house batteries to the starter.

  • Page 27: Driving Your Motorhome

    SECTION 3 – DRIVING YOUR MOTORHOME The information in this section refers only to features installed or adapted to the dash and Lift to Recline driver compartment area by Winnebago ® Industries . It also includes passenger seating in the living area of the coach.
  • Page 28 SECTION 3 – DRIVING YOUR MOTORHOME Armrest Adjustment –If Equipped The armrests may be swung upward out of the way for easy exit or access to the front seats. A roller on the underside of the front of the armrest also lets you adjust the resting angle for personal comfort, whether the seat is upright or reclined.

  • Page 29: Seat Belts

    SECTION 3 – DRIVING YOUR MOTORHOME time, and do not let the safety belts become damaged by pinching them in the doors or in the seat mechanism. After any serious accident, any seat belts which were in use at the time must be inspected and replaced if necessary.

  • Page 30: Child Restraints

    SECTION 3 – DRIVING YOUR MOTORHOME Lap/Shoulder Belts CHILD RESTRAINTS Fastening –If Equipped Hold the belt just behind the tongue. Next, A properly installed and secured child bring the belt across the body and insert the restraint system can help reduce the chance or tongue into the buckle until the latch engages.

  • Page 31: Keyone Lock System

    The key number for your coach is registered in Mirror Heat Switch our factory database, so if you ever lose your ® (Located on dash) keys, any Winnebago Industries dealership can -Typical View order a new key for you.

  • Page 32: Accent Led Light Strips (Front)

    SECTION 3 – DRIVING YOUR MOTORHOME Mirror Arm/Head Adjustment If you cannot adjust a mirror properly using the control switch, the mirror may need a coarse adjustment by rotating the mirror head. • Sideview Camera ACCENT LED LIGHT STRIPS (FRONT) Mirror Head Pivot Lock •...

  • Page 33: Front Drop-Down Shade (12-Volt)

    FRONT DROP-DOWN SHADE motor failure. (12-VOLT) Should the Automatic Safety Retraction feature deploy, go to your nearest Winnebago Your coach is equipped with a 12V Front ® Industries dealer for service before operating Windshield Visor/Shade that provides privacy the shade again.
  • Page 34 SECTION 3 – DRIVING YOUR MOTORHOME Satellite Radio NOTE:The camera polarity setting needs to be –If Equipped set to “Battery” for automatic camera viewing when the vehicle is put into Your coach may be equipped with a reverse. This can be set by pushing the ®...

  • Page 35: Radio In-Dash/Rearview Monitor System

    SECTION 3 – DRIVING YOUR MOTORHOME Radio Remote Control This system is also featured with a rearview camera monitor system, which lets you see what A hand-held remote control for the radio lets is directly behind your coach for safety and you control the radio from a distance for your maneuvering assistance.

  • Page 36: Radio Power Switch

    SECTION 3 – DRIVING YOUR MOTORHOME Sideview Cameras The sideview cameras (built into the driver and passenger side mirrors) activate with the corresponding turn signals and replace the rear camera view on the monitor until the turn is completed or the signal lever is canceled manually.

  • Page 37: Cb Radio Power Wiring

    SECTION 3 – DRIVING YOUR MOTORHOME PARKING BRAKE ® Freightliner Chassis Radio Power Switch (Located on lower dash area) • Press HOUSE to listen to the radio while parked without the ignition key on. Parking Brake Knob • Press ENGINE (“ENG”) to listen while driving. -Typical View •...

  • Page 38: Hazard Warning Flashers

    SECTION 3 – DRIVING YOUR MOTORHOME This controlled back pressure helps to regulate possible hazard to other motorists. When the a vehicle’s downhill speed, such as on flashers are on, it serves as a warning to other mountainous or hilly roads. It also provides drivers.

  • Page 39: Signal Lever/Headlight High-Low Beam

    SECTION 3 – DRIVING YOUR MOTORHOME SIGNAL LEVER/HEADLIGHT HIGH-LOW BEAM The signal lever controls the turn signals and headlight high/low beams. Headlight Switch (Located on left side of dash) -Typical View Further Information Refer to the chassis manual provided in your InfoCase for additional information on the Headlight switch.

  • Page 40: Battery Boost Switch

    SECTION 3 – DRIVING YOUR MOTORHOME AIR CONDITIONER/HEATER – WARNING AUTOMOTIVE (DASH) Controls for the air conditioner, heater, defroster, and vent are located on the dash. Do not adjust the steering column or tilt wheel while the vehicle is in motion. Doing so may cause loss of vehicle control resulting in death or personal injury.

  • Page 41: Fuel Selection - Diesel Engine

    SECTION 3 – DRIVING YOUR MOTORHOME FILLING THE FUEL TANK – DIESEL ENGINE Diesel fuel can foam up while being pumped into the tank. Sometimes this foam can cause the pump nozzle to shut off before the tank is actually full. Allow the foam to settle, then resume filling at a slower flow rate until the tank is full.

  • Page 42: Engine Access Covers - Rear

    SECTION 3 – DRIVING YOUR MOTORHOME Model 34T rear cargo compartment on the driver side of the coach. When plugged into the receptacle, the Forward Engine Access Cover heater is connected to both the shoreline and the The Forward Engine Access Cover is auxiliary generator, so a separate extension cord accessed by lifting the foot of the bed board.
  • Page 43 SECTION 3 – DRIVING YOUR MOTORHOME 2. Disconnect air bed hoses from the pump 7. Remove bed board and set aside in another (located beneath the bed board). area of the coach. 8. Remove fasteners from metal engine cover (rearward) and set aside to access engine. 9.

  • Page 44: Front Service Access

    SECTION 3 – DRIVING YOUR MOTORHOME FRONT SERVICE ACCESS (HOOD) The hood panel can be opened for access to service items such as the Windshield Washer Fluid Reservoir and Generator Oil Dipstick. To Open Hood • Unlock front Hood Locks with the Ignition Key.

  • Page 45: Fuel/Water Separator - Diesel

    SECTION 3 – DRIVING YOUR MOTORHOME With the grille panel open, you can access the FUEL/WATER SEPARATOR – following service points: DIESEL • Engine Oil Dipstick ® Freightliner Chassis • Engine Oil Fill Diesel fuel often contains small quantities of •...

  • Page 46: Diesel Exhaust Fluid Fill

    SECTION 3 – DRIVING YOUR MOTORHOME Further Information Refer to the chassis manual provided in your InfoCase for complete information and precautions. ENGINE COOLING SYSTEM Do not remove the radiator cap while engine and radiator are still hot. Always check coolant level visually at the see-through coolant reservoir.

  • Page 47: Circuit Breakers And Fuses - Chassis/Dash Automotive 12-Volt

    SECTION 3 – DRIVING YOUR MOTORHOME Automotive Circuit Breakers (push to reset) Chassis Battery Disconnect Switch • Breakers are labeled for components equipped (Located near entrance door) -Typical View Turn the switch to the OFF or ON positions to disconnect or reconnect the chassis batteries. NOTE: The Chassis Battery Disconnect switch must be on to start the engine.

  • Page 48: Windshield Washers And Wipers

    SECTION 3 – DRIVING YOUR MOTORHOME Further Information SUSPENSION ALIGNMENT See your chassis manual in your InfoCase for AND TIRE BALANCE further information about chassis supplied fuses and relays. The front suspension and steering system of this vehicle was factory aligned using highly WINDSHIELD WASHERS AND accurate equipment prior to delivery to the dealership.
  • Page 49 SECTION 3 – DRIVING YOUR MOTORHOME Further Information Refer to the chassis manual in your InfoCase for further information. 3-23...

  • Page 51: Appliances And Systems

    SECTION 4 – APPLIANCES AND SYSTEMS The appliances installed in your motorhome are manufactured by reputable RV appliance makers and have been tested by independent laboratories to meet all applicable standards and codes set for RV appliances. See Section 2 - Safety and Precautions of this manual for any safety and precautions you need to take regarding the operation of your appliances.

  • Page 52: Ice Maker

    SECTION 4 – APPLIANCES AND SYSTEMS See the manufacturer’s user guide provided in REFRIGERATOR SERVICE your InfoCase for information on adjusting ACCESS COMPARTMENT – refrigerator/freezer temperatures to best suit your RESIDENTIAL needs. NOTE: Allow 24 hours for your refrigerator to (Exterior) cool completely before storing food.

  • Page 53: Range Top

    SECTION 4 – APPLIANCES AND SYSTEMS To Light Range Top Burners • Depress the desired burner knob and turn counter-clockwise to the ON or LITE position (do Microwave Oven/Range Hood NOT attempt to light more than one burner at a (Brand, model, and appearance shown may time).

  • Page 54: Systems Monitor Panel

    SECTION 4 – APPLIANCES AND SYSTEMS Unlike homes, the amount of oxygen supply is pump and water heater. Indicator lights tell you if limited due to the size of the recreational vehicle, the water pump is on or if the water heater pilot and proper ventilation when using the cooking light is out.

  • Page 55: Power Control System (Pcs)

    SECTION 4 – APPLIANCES AND SYSTEMS Tank Capacities See “Tank Capacities” in Section 1 - Introduction. Propane Gas Level Press and Hold the Levels Test switch to show approximate propane tank level. The propane level is registered by a sending unit on the tank.

  • Page 56: Water Heater - Gas

    SECTION 4 – APPLIANCES AND SYSTEMS Further Information Further Information Refer to the manufacturer’s user guide See the Water Heater manufacturer’s provided in your InfoCase for important operation manual provided in your InfoCase for information on how this system operates under complete operating instructions, safety warnings, several conditions, whether 20-amp, 30-amp, or and maintenance information.

  • Page 57: Pressure-Temperature Relief Valve

    SECTION 4 – APPLIANCES AND SYSTEMS PRESSURE-TEMPERATURE RELIEF VALVE On occasion, water may be seen seeping from the water heater pressure temperature relief valve. This is no cause for repair or replacement of the valve. Gas Water Heater Switch (Located on Systems Monitor Panel) For Electric Operation Turn on the Water Heater electric element switch.

  • Page 58: Furnace - Propane Gas

    SECTION 4 – APPLIANCES AND SYSTEMS • Lift handle straight out to open P-T valve Thermostat Switch Temp Selector when water heater is cold. • Move to Heat or Gas • Press up or -Typical View down to select position for furnace operation temperature 4.

  • Page 59: Heat Pump

    SECTION 4 – APPLIANCES AND SYSTEMS Further Information when outside temperatures begin to reduce the efficiency of the Heat Pump. The Heat Pump will Refer to the manufacturer’s user guide not operate when the outside temperature falls provided in your InfoCase for further below 36 degrees F.

  • Page 60: Air Conditioner Filter

    SECTION 4 – APPLIANCES AND SYSTEMS NOTE: The ducted roof air conditioning system has ceiling registers that can be closed if necessary to force more cool air toward a specific area of the coach or to route cool air away from a specific area. If too many vents are closed, however, it can cause the air conditioner unit to shut down, particularly in high humidity...

  • Page 61: Washer/Dryer (Model 38R)

    SECTION 4 – APPLIANCES AND SYSTEMS Further Information Refer to the manufacturer’s user guide provided in your InfoCase for complete operating instructions, troubleshooting and maintenance tips, and safety precautions. WASHER/DRYER (MODEL 38R) –If Equipped Your coach may be equipped with a Washer/ Dryer for the luxury of home as you travel.

  • Page 62: Washer/Dryer - Prep Package

    Dryer, plumbing may be present for installation. Typically, the plumbing lines are located inside the wardrobe or storage cabinet depending on model. We recommend obtaining parts and service for the Washer/Dryer installation from your ® ® Winnebago or Itasca dealer. 4-12...

  • Page 63: Propane Gas

    SECTION 5 – PROPANE GAS PROPANE GAS SUPPLY Tank Gauge & Tank Fill Overflow Sender The propane gas system supplies fuel for the Valve Valve gas range/oven, water heater, furnace, and refrigerator (while in gas mode). When used and handled properly, this system is safe and economical and provides modern living conveniences wherever you travel.

  • Page 64: Safe Use Of The Propane Gas System

    SECTION 5 – PROPANE GAS propane gas outlets in the United States do not offer any other type of liquefied petroleum gas WARNING than propane to the general public.) Check local phone directory yellow pages for locations of local propane gas refilling stations or bulk Do not fill propane container(s) to more dealerships.

  • Page 65: Propane Gas Warnings And Precautions

    SECTION 5 – PROPANE GAS Here are a few precautions to observe that will PROPANE GAS WARNINGS help you to use the propane gas system safely: AND PRECAUTIONS • Exercise caution at all times. Be familiar with the distinctive odor of propane gas. If a leak is It is illegal for vehicles equipped with propane suspected, turn off the supply valve container to travel on certain roadways or...

  • Page 66: Propane Gas Pressure Regulator

    SECTION 5 – PROPANE GAS WARNING WARNING Do not place propane cylinders inside the Visually inspect the pressure regulator vehicle. vent periodically for blockage by Propane cylinders are equipped with accumulated debris or insect nests, etc. safety devices that relieve excessive Vent obstruction could result in excessive pressure by discharging propane to the pressure causing fire or explosion, which...

  • Page 67: Propane Vaporization In Cold Weather

    SECTION 5 – PROPANE GAS This means that in extremely cold weather when a large volume of gas is being used by the furnace for heating, it is possible to experience a loss of gas pressure. At first, this problem may appear to be caused by an empty tank or a regulator freeze-up, but is actually caused by failure of the liquid gas to vaporize as fast as it is needed by the furnace.

  • Page 69: Electrical

    SECTION 6 – ELECTRICAL Your coach is equipped with an electrical the power converter automatically changes a system consisting of two separate voltages: portion of the 120-volt current to 12-volt DC current. All equipment in the motorhome that is • 12-volt DC system (battery current);...

  • Page 70: Connecting The Power Cord

    SECTION 6 – ELECTRICAL be used is designed to mate with the prongs of the power cord plug, the electrical connection can be WARNING expected to carry rated load. Connecting The Power Cord This connection is for 208Y/120-Volt or To connect to an external source, remove the 120/240 Volt AC, 3-pole, 4 wire, 60 Hz cord from the utility compartment and plug it into Ampere supply.

  • Page 71: Inverter/Charger Unit - 2000W

    SECTION 6 – ELECTRICAL The inverter can also be used while driving the motorhome because the engine alternator will charge the batteries while driving. The inverter/charger unit is located in the utility compartment or mid-passenger side compartment, depending on model. WARNING Service inlet access must be closed when utility connections are not in use.

  • Page 72: Circuit Breakers - House 120-Volt Ac

    SECTION 6 – ELECTRICAL The inverter/charger features a Battery mode, it will continue to draw from ™ Saver Mode, which is designed to keep house batteries through the inverter batteries fully charged over long periods of time. when the shoreline is unplugged unless See the inverter/charger information included in the inverter is turned OFF.

  • Page 73: Electrical Outlets - House 120-Volt Ac

    SECTION 6 – ELECTRICAL ELECTRICAL OUTLETS – HOUSE 120-VOLT AC WARNING A number of standard household electrical outlets are provided throughout the coach for The GFCI will not completely eliminate connecting small appliances such as televisions, the risk of electrical shock. Infants and radios, toasters, etc.

  • Page 74: Generator Hourmeter

    SECTION 6 – ELECTRICAL Generator Hourmeter The Generator Hourmeter registers the total number of hours that the Generator has been operated. Refer to the Hourmeter to determine when periodic maintenance is due and to record services which have been performed. Further Information See the Generator manufacturer’s user guide provided in your InfoCase for more information...

  • Page 75: Electrical System - House 12-Volt Dc

    SECTION 6 – ELECTRICAL NOTE: Check Generator oil level frequently The house batteries can also provide during periods of use. Refer to the emergency power to start the engine if the chassis Generator manufacturer’s user guide battery is discharged. (See “Battery Boost provided in your InfoCase for specific Switch”...

  • Page 76: House/Coach Battery Disconnect Switch

    SECTION 6 – ELECTRICAL discharged. (See “House/Coach Battery Disconnect switch” or “Battery Boost switch” in Section 3 - Driving Your Motorhome). The house batteries are automatically charged by the chassis alternator while the engine is running. HOUSE/COACH BATTERY DISCONNECT SWITCH (COACH BATT) The House/Coach Battery Disconnect switch lets you disconnect the house batteries from the...
  • Page 77 SECTION 6 – ELECTRICAL energy is removed from the battery, it should be replaced by the engine alternator or the coach WARNING converter system. If a battery sits unused for 30 days or more, especially during warm weather, it can develop a California Proposition 65 Warning: deposit of sulfate crystals on the metal plates Battery posts, terminals, and related...

  • Page 78: Circuit Breakers - House 12-Volt

    If your coach is going to be unoccupied for year. ® two weeks or more, Winnebago Industries • Check the battery fluid level every month, or recommends disconnecting the chassis batteries more often in hot weather. Fill to in your coach to avoid battery discharge.
  • Page 79 SECTION 6 – ELECTRICAL House Circuit Breakers -Typical View Typical view of breaker panel. Actual breaker panel location may vary according to model floorplan. Breakers are labeled on panel according to appliance and equipment options. 6-11...

  • Page 81: Plumbing

    SECTION 7 – PLUMBING The tank is filled through the City Water FRESH WATER SYSTEM Connection (Fresh Water Inlet) located inside the water service center. The Fresh Water System provides water to the galley sink, shower, bathroom lavatory, toilet, The Fresh Water valve routes the water from and water heater.

  • Page 82: Water Pump

    SECTION 7 – PLUMBING 4. Use the level display on the monitor panel to NOTE: Always keep the Fresh Water valve in oversee filling of the tank, or when the tank is Normal position unless you are filling the full, water will flow from tank vent tube tank.

  • Page 83: Water Pump Switch

    SECTION 7 – PLUMBING Pump system. Thereafter, remember to slow leak in a faucet could drain the water tank, check it at least yearly, and be sure to fill the holding tank, and discharge the house empty water from it during winterization batteries.

  • Page 84: Full-Coach Water Filtration System

    SECTION 7 – PLUMBING FULL-COACH WATER FILTRATION SYSTEM –If Equipped The full-coach water filtration system is connected to the cold water lines throughout the coach. It uses a flow-through filter that removes chlorine, cloudiness, and sediments, resulting in clear, odorless and taste-free clean water for drinking, cooking, and personal care.

  • Page 85: Disinfecting Your Fresh Water System

    SECTION 7 – PLUMBING • Turn the Fresh Water Valve to Normal 2. Prepare a chlorine solution using 1 gallon of position. Next open a faucet inside the coach water and 1/4 cup of household chlorine or the exterior shower, then turn city water on bleach (sodium hypochlorite solution).

  • Page 86: Shower Hose Vacuum Breaker

    SECTION 7 – PLUMBING 3. Remove the Full-Coach Water Filtration (after closing the shower faucet) slowly releases cartridge from the filter canister. Refit empty and allows water remaining in the hose to drain canister to filter head for procedure. down. This is a normal function of the shower valve assembly and is not a leak or defect.

  • Page 87: Toilet - Electric Flush

    SECTION 7 – PLUMBING Water Saver Flush Normal Flush Important “Don’ts” • Don't use facial tissue or regular toilet tissue in the RV toilet. These will not disintegrate LED Symbol sufficiently and will often cling to the sides of the holding tank. Toilet tissue made specifically for use in RV toilets and holding Wall Switch/Controller tanks is available at most RV supply centers.

  • Page 88: Drainage System (P-Traps)

    SECTION 7 – PLUMBING See winterizing instructions at the end of this 2. Remove dust cap from sewage drain outlet section to prepare the toilet for storage in freezing and connect sewage drain hose. Be sure it is conditions. firmly attached. Further Information •...
  • Page 89 SECTION 7 – PLUMBING 3. Attach a garden hose from a city water • 1st - Pull Black hydrant to the Black Waste Tank Flush Inlet Waste Tank fitting in the water service center. (This inlet is Drain Valve to clearly marked separate from the City Water drain Black inlet).

  • Page 90: Waterline And Tank Drain Valves

    SECTION 7 – PLUMBING Water Tank Drain Valve miles to dislodge the solids. A few starts and stops will aid in the process. Then reconnect the hose and drain in the normal manner. NOTE: Always keep sewage drain outlet capped while sewage connection is not in use.
  • Page 91 A blow-out plug can be purchased at any element. Drain the water heater by removing ® ® the plug from the base of the water heater tank, Winnebago or Itasca dealer. accessible from the outside of the coach. (Requires socket and ratchet).

  • Page 92: Winterizing Optional Appliances

    SECTION 7 – PLUMBING NOTE: It is not necessary to add antifreeze to the toilet since the flush valve will be closed. City Water Connection Do not add automotive antifreeze or caustic chemicals such as bleach or laundry detergents into the toilet bowl or holding tanks.
  • Page 93 SECTION 7 – PLUMBING 3. Turn Ice Maker Winterization Drain valve to the CLOSED position. 4. Turn the water supply ON. 5. Ensure the ice bin is in place and the wire shut- off arm is lowered to the ON position. 6.

  • Page 94: Water System Drain Valve Locations

    SECTION 7 – PLUMBING WATER SYSTEM DRAIN VALVE LOCATIONS System Drain Valve Locations Waterline Drain Valves • Model 34T: Two (2) waterline drain valves located inside the water pump compartment (second compartment on driver side). Open exterior shower faucet and lay shower head on ground.

  • Page 95: Entertainment

    SECTION 8 – ENTERTAINMENT AUDIO/VIDEO SYSTEM BASIC • On the DVD OPERATION player, press the PLAY button. NOTE: For your convenience, we have also included a handy, tear-out version of this “A/V System Basic Operation” guide in • On the DVD player Section 8 of your Operator’s Manual Remote, press the Supplement.

  • Page 96: Tv - Bedroom (Flip Down)

    SECTION 8 – ENTERTAINMENT Further Information FRONT TV IGNITION SWITCH See the manufacturer’s user guide provided in INTERLOCK your InfoCase for complete feature descriptions and operating instructions. –If Equipped If your coach is equipped with a front TV – BEDROOM (FLIP DOWN) overhead TV, it is plugged into a special electrical outlet with a built-in ignition switch –If Equipped...

  • Page 97: Tv Signal Amplifier

    SECTION 8 – ENTERTAINMENT 6. Rotate antenna to illuminate the last flickering LED light. 7. Repeat Steps 5 and 6 to pinpoint signal reception. NOTE: Refer to television manufacturer’s instructions to scan for available channels. Further Information See the antenna manufacturer’s user guide Digital Antenna Power Switch provided in your InfoCase for complete operating (Located in an overhead cabinet or...

  • Page 98: Tv Digital Satellite System Wiring

    TV (if TV DIGITAL SATELLITE equipped). SYSTEM – AUTOMATIC ® See your authorized Winnebago Industries –If Equipped dealer for proper installation and sealing of roof The Automatic Multi-Satellite Television mounted components. System allows you to receive TV programs directly from satellite to your coach.

  • Page 99: Exterior Entertainment Center (Adjustable)

    SECTION 8 – ENTERTAINMENT • When activated while parked, the dish mounted on an adjustable bracket which allows antenna will seek the selected satellite you to angle the TV to best suit your viewing automatically. needs. NOTE: Refer to “HDMI Video Selection System”...
  • Page 100 SECTION 8 – ENTERTAINMENT 2. Pull the TV out and pivot to desired position. 3. Rotate TV back to center position and press straight back. You will hear a “click” when the TV is secured into locked position. Further Information Please read the manufacturer’s user guide in your InfoCase for complete operating instructions.

  • Page 101: Furniture And Softgoods

    SECTION 9 – FURNITURE AND SOFTGOODS SLEEPING FACILITIES WARNING Sleeping facilities are not intended for use while vehicle is in motion. For safety, passengers must use safety belted seating positions while vehicle is in motion. Lounge Chair Base Clamp (Travel position shown) LOUNGE CHAIR –...

  • Page 102: Dinette/Bed Conversion - Dream Dinette

    SECTION 9 – FURNITURE AND SOFTGOODS 3. Release the lock rod on the bottom of the DINETTE/BED CONVERSION – dinette table by pulling down. DREAM DINETTE ™ Lock Rod –If Equipped (Typical View – Your coach may differ in appearance) 4.

  • Page 103: Flex Bed

    SECTION 9 – FURNITURE AND SOFTGOODS Reverse steps to convert back into dinette seating. Once the table is up, engage the lock rod by pushing the lock rod up. Dinette to Bunk Beds 1. Lift the table top upward off the support tube and set aside.

  • Page 104: Fold And Tumble

    SECTION 9 – FURNITURE AND SOFTGOODS 5. Lower the bunk by pressing the Bunk Switch (located near the wardrobe) DOWN. Reverse steps to reassemble to dinette configuration. WARNING NOTE: This low bunk design may be accessed Keep people away from operating without the use of a ladder.

  • Page 105: Inlounge

    SECTION 9 – FURNITURE AND SOFTGOODS INLOUNGE –If Equipped WARNING (Typical View – Your coach may differ in appearance) Stow sofa extensions before retracting Dinette Extension slide rooms. Failure to observe can cause 1. Engage and Hold the black lever (located on injury and will cause equipment damage.

  • Page 106: Intable

    SECTION 9 – FURNITURE AND SOFTGOODS Reverse steps to store bed into dinette 4. Repeat Steps 1 through 3 on opposite dinette position. seat. Reverse steps to store the sectional dinette INTABLE extensions. –If Equipped inTable Leg Adjustment WARNING It may be necessary to adjust the height of the inTable leg(s).

  • Page 107: Power Loft Bed

    SECTION 9 – FURNITURE AND SOFTGOODS Reverse steps to store the loft bed. Loft Bed Operation NOTE: This low bunk design may be accessed NOTE: Make sure cab seat armrests are in the without the use of a ladder. If needed, a down position before lowering the loft multi-purpose step stool may be used.
  • Page 108 SECTION 9 – FURNITURE AND SOFTGOODS 2. Turn the key (located on the right sidewall To install the Mesh Netting behind the passenger seat) to the “ON” • Your Power Loft Bed is equipped with mesh position. netting (located in the wardrobe) that may be installed to the front side of the bed and front cabinet face.
  • Page 109 SECTION 9 – FURNITURE AND SOFTGOODS • The bed is now ready for use. To access the Loft Bed see “Loft Bed Ladder” later in this section. • Maximum Capacity: 300 lbs. • To avoid injury to young children, do not leave them unattended on the bunk.
  • Page 110 SECTION 9 – FURNITURE AND SOFTGOODS • Never ignore warning labels or weight limits defined on your ladder. The following warning label is located on or near the ladder: WARNING Do not exceed 225 lbs. maximum weight capacity. Misuse of ladder could result in death or serious injury.

  • Page 111: Digital Sleep Air Bed

    SECTION 9 – FURNITURE AND SOFTGOODS DIGITAL SLEEP AIR BED ® by Innomax –If Equipped • Memory feature allows • Adjust to • Display instant return to your Softer Indicator favorite sleep number Setting Attaching Bunk Ladder 3. Lower ladder to floor. •...

  • Page 112: Roller Shades (Manual) - Solar/Blackout

    No matter which species you chose for your -Typical View new Winnebago Industries motorhome cabinetry, please keep in mind that no two pieces Further Information of wood are exactly the same.
  • Page 113 SECTION 9 – FURNITURE AND SOFTGOODS Additionally, wood species exhibit other defining characteristics, such as mineral deposits/streaks, knots, sap runs, pin holes, and wormholes. These markings make the wood unique and contribute to its enduring beauty. Therefore, since wood is a product of nature and will have certain natural characteristics and variances, they are not covered under the warranty.

  • Page 115: Slideout Rooms And Leveling

    The ignition key must be placed in the on or run position to operate the slideout room(s). The park brake must be applied for the room(s) to run. Winnebago recommends running the engine whenever you run the slideout rooms in or out, the engine alternator should insure the rooms have adequate 12-volt DC power to operate correctly.
  • Page 116 SECTION 10 – SLIDEOUT ROOMS AND LEVELING • Ensure exterior compartment doors are closed so that they will not interfere with slideout WARNING operation. • Check inside and outside the vehicle to make sure that there are no people who could be CRUSH HAZARD.

  • Page 117: Slideout Room - Extreme Weather Precaution

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING interior slideout control switch. This SLIDEOUT ROOM – EXTREME momentarily connects the house batteries to WEATHER PRECAUTION assist in slideout room operation. • The circuit breaker may be tripped. The Certain extreme weather conditions, such as circuit breaker, labeled “Slideout Power”...

  • Page 118: Slideout Room Troubleshooting (Power Gear®) In Wall Slideout

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING • (5) - EXCESSIVE MOTOR CURRENT. SLIDEOUT ROOM High amperage (also indicated by one side of TROUBLESHOOTING (POWER slideout room continually stalling). GEAR ) IN WALL SLIDEOUT ® • (6) - MOTOR SHORT CIRCUIT. Motor or wiring to motor has shorted out.

  • Page 119: Slideout Room Troubleshooting (Power Gear®) Under Floor Slideout

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING Slideout manufacturer’s user guide in your • Light will flash fault • Light will flash if InfoCase to determine the problem. The error code if system park brake not set code must be cleared prior to operating the room. malfunctions Further Information See the In Wall slideout room operating guide...
  • Page 120 SECTION 10 – SLIDEOUT ROOMS AND LEVELING Manual Mode • Light will flash fault • Light will flash if Manual Mode lets you individually move the code if system park brake not set two room arms by pressing the IN and OUT malfunctions buttons on the touchpad.

  • Page 121: Slideout Emergency Retraction (Lippert)

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING 3. Remove the top (4) pan head screws and top SLIDEOUT EMERGENCY (4) flat head screws at the top of the aluminum RETRACTION (LIPPERT) trim. –If Equipped If the slideout mechanism is malfunctioning and the room will not retract using the interior control switch or exterior control panel, you may need to access the slideout motors and manually...

  • Page 122: Slideout Emergency Retraction (Power Gear ) In Wall Slideout

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING 7. When the slideout room is fully retracted, secure the room with a support item (e.g. 2x4 wood board) above the interior slideout room to secure room during travel. NOTE: For larger slideout rooms, place a travel support item on each end of the interior slideout room.

  • Page 123: Slideout Emergency Retraction (Power Gear ) Under Floor Slideout

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING SLIDEOUT EMERGENCY 3) Use 3/4”socket on gearbox RETRACTION (POWER GEAR shaft to crank room in ® UNDER FLOOR SLIDEOUT –If Equipped If the slideout mechanism is malfunctioning and the room will not retract using the interior control switch, you may need to access the motor/gear assembly and manually crank the room in to the travel position.

  • Page 124: General Slideout Care

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING Further Information Lippert See the Under Floor Slideout Room operating guide included in your InfoCase for further instructions and troubleshooting information. GENERAL SLIDEOUT CARE • Keep slideout room seals clean. • Clean the floors inside the coach before retracting the slideout room to avoid floor scratches or carpet pile snags.
  • Page 125 SECTION 10 – SLIDEOUT ROOMS AND LEVELING “Jacks Down” Light (Located on dash) WARNING -Typical View • Keep all people clear of the coach while the leveling system is operating. NOTICE • When extending the rear stabilizers, do not lift the wheels beyond ground contact.

  • Page 126: Checking Hydraulic Oil Level

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING 3. Visually inspect the vehicle undercarriage for Model 34T any problems. Breather/Fill Cap 4. See the Leveling System Operation Guide supplied in your InfoCase for troubleshooting instructions or operating the Leveling System if jacks fail to retract or any other functions fail.
  • Page 127 SECTION 10 – SLIDEOUT ROOMS AND LEVELING Hydraulic Fluid Recommendation The leveling system is filled from the factory with AW-22S synthetic hydraulic oil that has been specially formulated for use in the leveling system and that is compatible with Automatic Transmission Fluid (ATF).

  • Page 129: Maintenance And Storage

    • Have the sealant replaced if you notice any of attention. Delaying these repairs may allow water the above. Your local Winnebago Industries leakage and result in damage to interior ceiling dealer has the correct and necessary parts and and body panels, upholstery, etc., which is not experience to help you maintain your sealants.

  • Page 130: Exterior Automotive Paint Finish

    SECTION 11 – MAINTENANCE AND STORAGE weight to the vehicle. This, in effect, reduces the • Do not scrape ice or snow from the painted amount of cargo you can carry and remain within surface. Brush off gently with a soft-bristled GVWR and GAWR limits.
  • Page 131 SECTION 11 – MAINTENANCE AND STORAGE Washing NOTE:Avoid aiming water flow from a hose or spray from high-pressure washing • Commercial vehicle wash facilities should be equipment into any appliance intake, as strictly avoided! They will scratch your RV! damage or difficulty in operating Truck-style wash centers have high- appliances may occur.

  • Page 132: Exterior Graphic Care

    SECTION 11 – MAINTENANCE AND STORAGE Further Information • Avoid paste waxes. They sometimes have fillers and additives that give a very short term See the manufacturer’s information provided result. Stay away from silicones in polishes in your InfoCase for complete care and and soaps.

  • Page 133: Plastic Parts - Cleaning

    LIGHTS cleaning products to use on plastic parts. Exterior Light Lenses ® Most Winnebago Industries vehicles have NOTICE polycarbonate lenses on exterior lamps, which are very sensitive to a variety of chemical Do not use citrus-based cleaners on solvents and cleaners.

  • Page 134: Interior Soft Goods

    SECTION 11 – MAINTENANCE AND STORAGE automobiles. This type of lamp assembly is not sealed from the atmosphere and is designed with WARNING a moisture venting system. Because they are not sealed, under “dew point” conditions the headlights may exhibit When cleaning upholstery and fabric, do signs of humidity condensation on the reflector not use lacquer thinner, nail polish...

  • Page 135: Cabinetry - Cleaning

    SECTION 11 – MAINTENANCE AND STORAGE If a stain has dried on, allow the cleaner or CABINETRY – CLEANING soapy water time to soften the area, after which the stain will wipe off. Wooden items may be cleaned with a soft cloth and a good quality wood finish cleaning If the stain is not water-base or oil-base product.

  • Page 136: Tables And Countertops

    SECTION 11 – MAINTENANCE AND STORAGE Oil and Grease Stains replacement. If one of these materials does spill or drip onto the counter surface, wipe it up To remove oil and grease stains, use a mild immediately to avoid damage. dishwashing liquid and hot water.

  • Page 137: Galley Sink

    SECTION 11 – MAINTENANCE AND STORAGE GALLEY SINK VINYL FLOORING Stainless Steel Care and Maintenance Care and Cleaning Instructions You can easily maintain the beauty of your The stainless steel sink can usually be cleaned vinyl flooring with little effort, by following with water and soap or detergent using a soft these recommendations: cloth or sponge.

  • Page 138: Vehicle Storage - Preparation

    SECTION 11 – MAINTENANCE AND STORAGE Door locks and hinges should be lubricated 7. Have the vehicle chassis completely serviced periodically with powdered graphite to ensure and lubricated. Be sure radiator antifreeze trouble-free operation and to protect against protection level is sufficient for the lowest freeze-up.

  • Page 139: Chassis Service And Maintenance

    SECTION 11 – MAINTENANCE AND STORAGE Ice Maker Start-Up 9. After flushing fresh waterlines, install a new water filter cartridge on the galley sink water • Flush antifreeze from the waterlines (if filter and/or full-coach water filtration system antifreeze fill winterization procedure was (if equipped).

  • Page 140: Chassis Diagnostic Connectors

    SECTION 11 – MAINTENANCE AND STORAGE • 12-Volt Automotive Fuse Panel • 12-Volt Automotive Breaker Panel Towing Package Fuses (Located in driver side rear compartment) -Typical View • Unhook (3) latches to remove cover. • See chassis manufacturer’s information on inside of cover.
  • Page 141 SECTION 11 – MAINTENANCE AND STORAGE Diagnostic Plug (Located on rear engine compartment shroud) -Typical View 11-13...

  • Page 142: Coach Maintenance Chart

    SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Propane Gas System ...
  • Page 143 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Safety Equipment Check operation of the following items: ...
  • Page 144 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Sealants ...

  • Page 145: Miscellaneous

    SECTION 12 – MISCELLANEOUS NOTE: We recommend that you dump all LOADING THE VEHICLE holding tanks before traveling to avoid carrying unnecessary weight. NOTE: Your motorhome’s load capacity is designated by weight, not by volume, so you cannot necessarily use all available WARNING space when loading your motorhome.
  • Page 146 SECTION 12 – MISCELLANEOUS Corner Weighing (Side-to-Side) You will first drive only your front wheels onto the scale pad, then drive ahead so that the The most accurate method of weighing a whole vehicle is on the scale, then finally pull off motorhome is to weigh each “corner”...

  • Page 147: Car Or Trailer Towing

    SECTION 12 – MISCELLANEOUS axle is 12,000 lbs., then the load on each rear dual listed Gross Weight Ratings. See “Vehicle set (left rear duals or right rear duals) should not Certification Label” in the Introduction section exceed 6,000 lbs. for information on gross weight ratings.

  • Page 148: Trailer Wiring Connector

    SECTION 12 – MISCELLANEOUS located outside our recommended limits) places The following diagram shows proper excessive stress on the hitch. This abuse of the connection of trailer or tow vehicle wiring to the ball mount and the hitch may cause premature coach light system.

  • Page 149: Fireplace

    Class 3 hitch may have a label limiting vertical tongue load to 350 lbs. All Winnebago Industries models equipped with a Class IV hitch have a label limiting vertical tongue load to 500 lbs. On a 228" wheelbase, a 500-lb. load on a hitch 11' from the rear axle will apply about 800 lbs.

  • Page 150: Fireplace

    SECTION 12 – MISCELLANEOUS Remote Operation Further Information Refer to the Fireplace user guide provided in your InfoCase for complete operating and maintenance instructions, as well as safety • ON-I/II precautions. • TIMER • FIRE FIREPLACE • OFF –If Equipped Fireplace Remote Control (Located inside InfoCase) •...

  • Page 151: Fireplace

    SECTION 12 – MISCELLANEOUS • POWER: The POWER button supplies FIREPLACE power to all the functions of the fireplace. The POWER button will put the insert in standby –If Equipped mode. This will turn off all functions at once but will hold the settings in the memory. By pressing the POWER button again the unit will turn on at the same settings.

  • Page 152: Step (Entry) - Electric

    SECTION 12 – MISCELLANEOUS • FLAME: Each time the flame button is pressed, the intensity of the flame decreases. There are (6) brightness levels you can cycle through and the OFF setting. • HEATER: Turns the heater function ON and OFF.

  • Page 153: Tool Storage

    SECTION 12 – MISCELLANEOUS Stationary Extended Mode - Step STORAGE COMPARTMENT Switch OFF DOORS (Step Remains Extended) The high-density gaskets used on the exterior With the Step power switch in the OFF storage compartments are designed to provide a position, the step will extend when the screen more positive seal against dust and weather.

  • Page 154: Awning - Power

    SECTION 12 – MISCELLANEOUS Awning Light Switches (Located near entrance door) Compartment Lights Switch -Typical View (Located near entrance door) -Typical View NOTICE AWNING – POWER Your coach is equipped with entry door and The A&E Power Patio Awning is patio power awnings to provide protection extremely durable and can be operated against outdoor elements, such as sun, light rain,...

  • Page 155: Stepwell Cover

    SECTION 12 – MISCELLANEOUS • Power OFF - The Off position shuts down the system. The awning cannot be extended or retracted in this mode. The Auto-Retract system is also disabled. Entry Door Awning -If Equipped Your coach may feature an entrance door awning for additional protection.

  • Page 156: Windows

    SECTION 12 – MISCELLANEOUS Emergency Retract Feature • To close, crank the window in snugly (by turning the window handle “clockwise”), then The stepwell cover is equipped with an back off 1/4 turn to help avoid glass warping, Emergency Retract feature in event of an which can result in wind noise.

  • Page 157: Power Roof Ventilator

    SECTION 12 – MISCELLANEOUS Dome Crank Fan Speed Fuse Knob Selector -Typical View Power Roof Ventilator To Operate Ceiling Ventilator 1. Turn the Dome Crank Knob to raise the dome about 3" or more to allow the turbine fan to operate.

  • Page 158: Effects Of Prolonged Occupancy

    SECTION 12 – MISCELLANEOUS Further Information See the power ventilator manufacturer’s operating instructions supplied in your InfoCase for further instructions, care, and cleaning information. EFFECTS OF PROLONGED OCCUPANCY Your motorhome was designed primarily for recreational use and short-term occupancy. If you expect to occupy your coach for an extended period, be prepared to deal with condensation and humid conditions that may be encountered.
  • Page 159 INDEX About this Manual ..........................1-1 Accent LED Light Strips (Front) ......................3-6 Air Conditioner Filter ........................... 4-10 Air Conditioner/Heater – Automotive (Dash) ..................3-14 Air Horns .............................. 3-14 Audio/Video System Basic Operation ....................8-1 Awning – Power ..........................12-10 Bathroom ..............................
  • Page 160 Index Electrical Outlets – House 120-Volt AC ....................6-5 Electrical System – House 120-Volt AC ....................6-1 Electrical System – House 12-Volt DC ....................6-7 Emergency Exits ............................. 2-7 Engine Access Covers – Rear ....................... 3-16 Engine Access Grille – Rear ......................... 3-18 Engine Block Heater –...
  • Page 161 Index Interior Soft Goods ..........................11-6 Inverter/Charger Unit – 2000W ......................6-3 Jump Starting ............................2-11 KeyOne™ Lock System ......................... 3-5 Leveling System ..........................10-10 Lights ..............................3-22 Loading ..............................2-6 Loading the Vehicle ..........................12-1 Loft Bed ..............................9-6 Lounge Chair –...
  • Page 162 Index Seat Belts ..............................3-3 Seats – Driver/Co-Pilot ........................... 3-1 Service and Assistance ..........................1-2 Shower Hose Vacuum Breaker ....................... 7-6 Signal Lever/Headlight High-Low Beam ..................... 3-13 Sleeping Facilities ........................... 9-1 Slideout Emergency Retraction (Lippert) ..................... 10-7 Slideout Emergency Retraction (Power Gear®) In Wall Slideout ............10-8 Slideout Emergency Retraction (Power Gear®) Under Floor Slideout ..........
  • Page 163 Index Washer/Dryer – Prep Package ......................4-12 Washer/Dryer – Stackable ........................4-10 Washer/Dryer (Model 38R) ........................4-11 Waste Water System ..........................7-8 Water Heater – Gas ..........................4-6 Water Heater – Gas/ Electric ........................4-6 Water Pump ............................7-2 Water System Drain Valve Locations ....................7-14 WaterLine and Tank Drain Valves .......................

This manual is also suitable for:

Forza

Table of Contents
