Winnebago SightSeer Owner's Manual

Winnebago SightSeer Owner's Manual

Hide thumbs Also See for SightSeer:
Table of Contents

Advertisement

Quick Links

See also: Basic Operation Manual , Manual
About this Manual ............................................................................................................................. 1-1
Safety Messages Used in this Manual ............................................................................................... 1-1
Pre-Delivery Inspection .................................................................................................................... 1-2
Front Axle Tire Alignment ................................................................................................................ 1-2
Service and Assistance ...................................................................................................................... 1-2
Reporting Safety Defects .................................................................................................................. 1-2
Occupant and Cargo Carrying Capacity Label ................................................................................. 1-3
Vehicle Certification Label ............................................................................................................... 1-4
specifications and Capacitites ........................................................................................................... 1-5
Owner and Vehicle Information ........................................................................................................ 1-7
2010 New Vehicle Limited Warranty ............................................................................................... 1-8
General Warnings .............................................................................................................................. 2-1
Driving Safety ................................................................................................................................... 2-1
Fuel and Propane Gas ........................................................................................................................ 2-1
LP Gas Leaks .................................................................................................................................... 2-2
Propane Gas Leak Detector ............................................................................................................... 2-2
Carbon Monoxide Warning ............................................................................................................... 2-3
Carbon Monoxide Alarm .................................................................................................................. 2-3
Smoke Alarm .................................................................................................................................... 2-4
Fire Extinguisher ............................................................................................................................... 2-4
Electrical ........................................................................................................................................... 2-5
Loading ............................................................................................................................................. 2-5
Maintenance ...................................................................................................................................... 2-5
Emergency Exits ............................................................................................................................... 2-5
Slideout Rooms ................................................................................................................................. 2-6
Formaldehyde Information ................................................................................................................ 2-6
Mold, Moisture, and Your Motor Home ........................................................................................... 2-7
Roof and Ladders .............................................................................................................................. 2-8
Roadside Emergency ......................................................................................................................... 2-8
Jump Starting .................................................................................................................................... 2-9
Engine Overheat ................................................................................................................................ 2-9
Seats - Driver/Co-Pilot ..................................................................................................................... 3-1
Seat Belts ........................................................................................................................................... 3-2
Child Restraints ................................................................................................................................. 3-3
Keys ................................................................................................................................................... 3-3
Rearview Monitor System ................................................................................................................. 3-4
Rev. 1016100517

TABLE OF CONTENTS

Copyright 2009 Winnebago Industries, Inc. All rights reserved.
Part No. 161500-10-011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SightSeer and is the answer not in the manual?

Questions and answers

Melodi V Dewey
June 4, 2025

What do you do if the battery died and you can't start the engine

0

Related Manuals for Winnebago SightSeer

Summary of Contents for Winnebago SightSeer

  • Page 1: Table Of Contents

    3 – DRIVING YOUR MOTOR HOME Seats – Driver/Co-Pilot ........................3-1 Seat Belts ............................3-2 Child Restraints ..........................3-3 Keys ..............................3-3 Rearview Monitor System ......................... 3-4 Rev. 1016100517 Part No. 161500-10-011 Copyright 2009 Winnebago Industries, Inc. All rights reserved.
  • Page 2 Table Of Contents Mirrors – Power Electric ........................3-5 Brake-Shift Interlock ........................3-5 Parking Brake – Foot Pedal ......................3-5 Parking Brake – Automatic/Pull-Button ................... 3-6 Grade Brake ............................3-6 Overdrive Switch ..........................3-6 Tow/Haul Transmission Mode ......................3-7 Map Light Switch ..........................3-7 Hazard Warning Flashers ........................
  • Page 3 Table Of Contents Propane Gas Warnings and Precautions ................... 5-3 Propane Gas Pressure Regulator ....................... 5-4 Propane Vaporization in Cold Weather .................... 5-5 6 – ELECTRICAL Electrical Cautions ..........................6-1 Electrical System – House 120-Volt AC ..................6-1 External Power Cord ......................... 6-1 Power Center .............................
  • Page 4 Table Of Contents TV Digital Satellite System Wiring ....................8-7 TV Digital Satellite System – Manual ....................8-7 Exterior Entertainment Center ......................8-8 9 – FURNITURE AND SOFTGOODS Lounge Chair – Swivel Glider ......................9-1 Table and Chairs ..........................9-1 Sleeping Facilities ..........................
  • Page 5 Table Of Contents Loading the Vehicle ........................12-1 Weighing Your Loaded Vehicle ..................... 12-1 Car or Trailer Towing ........................12-3 Trailer Wiring Connector ........................ 12-4 Towing Guidelines .......................... 12-4 Entry Step – Electric ........................12-5 Windows ............................12-6 Power Roof Ventilator ........................12-7 Manual Awning ..........................

  • Page 7: Introduction

    DANGER indicates a hazardous situation are intended as a guide, and in no way which, if not avoided, will result in death or extend the responsibilities of Winnebago serious personal injury. Industries beyond the standard written warranty as presented in this manual.

  • Page 8: Pre-Delivery Inspection

    National Highway Traffic Safety Administration delivery inspection of the chassis and all motor (NHTSA) in addition to notifying Winnebago home components. Industries, Inc. As a part of the pre-delivery inspection...

  • Page 9: Occupant And Cargo Carrying Capacity Label

    SECTION 1 – INTRODUCTION or go to their website at http://www.safercar.gov or write to: Administrator, NHTSA 1200 New Jersey Avenue S.E. Washington, D.C. 20590 You can also obtain other information about motor vehicle safety from the NHTSA website at http://www.safercar.gov OCCUPANT AND CARGO CARRYING CAPACITY LABEL This label is affixed in the driver’s area next to...

  • Page 10: Vehicle Certification Label

    These pressure levels must be maintained to assure proper handling, safety, 2. Chassis manufacture date. and fuel economy. 3. Month and year of manufacture at Winnebago ® 9. Rear Axle Wheel Configuration: Single or Industries Dual as it relates to the inflation.

  • Page 11: Specifications And Capacitites

    SECTION 1 – INTRODUCTION SPECIFICATIONS AND CAPACITITES Optional Optional Standard Standard Workhorse™ Workhorse™ ® ® Winnebago Sightseer Ford F53 22,000 Ford F53 22,000 W22 22,000 lb. W22 22,000 lb. lb. Chassis with lb. Chassis with Chassis with Chassis with 19.5" Tires 19.5"...
  • Page 12 Specifications and Capacities (Cont.) Optional Optional Standard Optional Standard Ford® F53 Workhorse™ Ford® F53 Workhorse™ ® Winnebago Sightseer Ford F53 22,000 22,000 lb. W22 22,000 lb. 22,000 lb. W22 22,000 lb. lb. Chassis with Chassis with Chassis with Chassis with Chassis with 19.5"...

  • Page 13: Owner And Vehicle Information

    Motor Home Serial Number __________________________________________________________ Chassis Vehicle Identification No. (VIN) ________________________________________________ Vehicle Mileage at Delivery __________________________________________________________ Selling Dealer Name ________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ ® YOUR WINNEBAGO INDUSTRIES DEALER /SERVICE CENTER Name ____________________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ Contact ____________________________________________Phone ________________________ CHASSIS SERVICE CENTER...

  • Page 14: 2010 New Vehicle Limited Warranty

    ITEMS NOT SUBJECT TO WARRANTY COVERAGE Winnebago Industries, Inc. of Forest City, Iowa, warrants each new Chassis, drivetrain and related components* Winnebago and Itasca motor home to the owner for recreational use Wheels* in the U.S.A. and Canada as follows:...
  • Page 15 If you are touring or have moved, contact any unresolved warranty disputes for recreational vehicles. This dispute Winnebago Industries motor home dealer in the United States or resolution program reviews eligible product and service related Canada for warranty service.

  • Page 17: Safety And Precautions

    SECTION 2 – SAFETY AND PRECAUTIONS • Use care when accelerating or decelerating on GENERAL WARNINGS a slippery surface. Abrupt speed changes can cause skidding and loss of control. • Only seats equipped with seat belts are to be occupied while the vehicle is moving. •...

  • Page 18: Lp Gas Leaks

    SECTION 2 – SAFETY AND PRECAUTIONS • All pilot lights must be extinguished and asphyxiation is greater when the appliance is appliances turned off while refilling the fuel used for long periods of time. Failure to comply tank or LP gas tank. could result in death or serious injury.

  • Page 19: Carbon Monoxide Warning

    SECTION 2 – SAFETY AND PRECAUTIONS The best protection against carbon monoxide entry into the vehicle body is a properly WARNING maintained engine exhaust and ventilation system. It is recommended that the exhaust system and body be inspected by a qualified EXPLOSION HAZARD: DO NOT use an motor home service center: open flame to test for gas leaks.

  • Page 20: Smoke Alarm

    InfoCase for further instructions. that is also listed for RV application. We Replacement recommend obtaining a replacement from your ® Winnebago Industries dealer. When replacing this alarm, we recommend replacing only with the same model, or with one Further Information that is also listed for RV application.

  • Page 21: Electrical

    MAINTENANCE your coach. We recommend obtaining a replacement only from your Winnebago • Do not remove the radiator cap while engine ® Industries dealer or a reliable RV parts supplier.

  • Page 22: Slideout Rooms

    SECTION 2 – SAFETY AND PRECAUTIONS SLIDEOUT ROOMS WARNING Your motor home may have more than one slideout room. Understand which switch operates which slideout room prior to operation. Make sure all slideout rooms are clear of people who could be harmed or obstacles that could cause damage prior to operating any slideout rooms.

  • Page 23: Mold, Moisture, And Your Motor Home

    Winnebago Industries ® of the nature of the use of a motor home, it is natural for a motor home to be introduced into an If Winnebago Industries determines that mold environment with mold spores. ® ® is present in the Winnebago...

  • Page 24: Roof And Ladders

    SECTION 2 – SAFETY AND PRECAUTIONS warranty period, Winnebago Industries will not • Make sure you are physically capable to provide any financial assistance to the repair of safely use the ladder. Strength, flexibility, and the condition. stability are required.

  • Page 25: Jump Starting

    Damage to the transmission or other (wheel lift or frame lift) type towing assembly for parts of the vehicle will occur. safe towing. ® Winnebago Industries does not assume responsibility for damage incurred while towing this vehicle. ENGINE OVERHEAT NOTE: Consult the chassis manual for any...
  • Page 26 SECTION 2 – SAFETY AND PRECAUTIONS NOTICE Operating a vehicle under a severe overheating condition can result in damage to the vehicle. For information on what to do in case of overheating, consult your chassis manual. 2-10...

  • Page 27: Driving Your Motor Home

    SECTION 3 – DRIVING YOUR MOTOR HOME The information in this section refers only to features installed or adapted to the dash and Lift to Recline driver compartment area by Winnebago ® Industries . It also includes passenger seating in the living area of the coach.

  • Page 28: Seat Belts

    SECTION 3 – DRIVING YOUR MOTOR HOME SEAT BELTS WARNING Seats intended for occupancy while the vehicle is in motion are equipped with seat belts for the protection of the driver and passengers. Snug and low belt positions are essential. This will ensure that the force exerted by Lap Belts the lap belt in a collision is spread over the...

  • Page 29: Child Restraints

    SECTION 3 – DRIVING YOUR MOTOR HOME Tether Anchor Loop • Inspect the belts and hardware periodically. Check for cuts, frays, and loose parts. -If Equipped Damaged parts should be replaced. Do not If your coach has a dinette, it may be equipped remove or modify the belt system.

  • Page 30: Rearview Monitor System

    SECTION 3 – DRIVING YOUR MOTOR HOME Basic Operating Instructions Keys have an identification number, either a small metal tag or stamped into the key head. These numbers are recorded on the vehicle’s component model/serial sheet, which is included in your InfoCase. In case keys are lost or stolen, Power your dealer or a locksmith can provide you with •...

  • Page 31: Mirrors - Power Electric

    SECTION 3 – DRIVING YOUR MOTOR HOME MIRRORS – POWER ELECTRIC –If Equipped Always adjust mirrors for maximum rear visibility before driving off. Make sure the seat is adjusted for proper vehicle control and that you are sitting back squarely into the seat. Mirror Adjustment Control The mirror control is located on the driver side armrest panel or the dash.

  • Page 32: Parking Brake - Automatic/Pull-Button

    SECTION 3 – DRIVING YOUR MOTOR HOME PARKING BRAKE – AUTOMATIC/PULL-BUTTON ™ Workhorse Chassis 18,000 lbs. GVWR This chassis is equipped with parking brakes that apply automatically when the transmission is shifted into Park. The pull-button parking brake knob is located on the dash to the right of the steering column.

  • Page 33: Tow/Haul Transmission Mode

    SECTION 3 – DRIVING YOUR MOTOR HOME Press the button at the end of the shift lever to engage Tow/Haul Mode when pulling a trailer or tow vehicle. Overdrive Switch Further Information -Typical View See the chassis manual in your InfoCase for further operating instructions and cautions.

  • Page 34: Battery Boost Switch

    SECTION 3 – DRIVING YOUR MOTOR HOME Further Information NOTE: The dash air conditioner/heater is not designed to heat and cool the entire See your chassis manual for instructions on interior of the coach, but is intended only activating, operating, and canceling hazard to provide heating and cooling for the warning flashers.

  • Page 35: Radio - In-Dash

    SECTION 3 – DRIVING YOUR MOTOR HOME Radio Power Switch RADIO - IN-DASH • Press HOUSE to listen to the radio while parked without the ignition key on. The radio in your coach can receive AM/FM • Press ENGINE to listen while driving. stereo.

  • Page 36: Front Service Access

    SECTION 3 – DRIVING YOUR MOTOR HOME FRONT SERVICE ACCESS (HOOD) The hood panel can be opened for access to service items such as: • Windshield Washer Fluid Reservoir • Brake Fluid Reservoir • Generator Oil Dipstick Release the hood by lifting UP on the Hood Latches (located on each side of interior hood), then pull the hood panel outward and raise into the open position.

  • Page 37: Engine Cooling System

    SECTION 3 – DRIVING YOUR MOTOR HOME ENGINE COOLING SYSTEM Do not remove the radiator cap while engine and radiator are still hot. Always check coolant level visually at the see-through coolant reservoir. NOTE: Your chassis engine cooling system is filled with special extended-life coolant that is not the same as common anti- freeze available at retail outlets.

  • Page 38: Tires

    SECTION 3 – DRIVING YOUR MOTOR HOME Any excessive or abnormal tire wear may indicate worn or misaligned suspension or steering, unbalanced tire, or other tire/suspension problem. Alignment can be affected by worn steering/ suspension parts or by incidents which happen during driving, such as hitting a curb, pothole, or railroad track, etc.

  • Page 39: Circuit Breakers And Fuses - Chassis/Dash Automotive 12-Volt

    SECTION 3 – DRIVING YOUR MOTOR HOME CIRCUIT BREAKERS AND MOUNTAIN DRIVING FUSES – CHASSIS/DASH Special techniques must be used when driving AUTOMOTIVE 12-VOLT in mountainous or hilly country. The 12-volt automotive fuses and breakers are Climbing A Hill conveniently located behind the panel beneath The transmission will automatically the left end of the dash in front of the driver’s downshift as needed to climb most hills.

  • Page 41: Appliances And Systems

    SECTION 4 – APPLIANCES AND SYSTEMS The appliances installed in your motor home are manufactured by reputable RV appliance makers and have been tested by independent laboratories to meet all applicable standards and codes set for RV appliances. See Section 2 of this manual for any safety and precautions you need to take regarding the operation of your appliances.

  • Page 42: Refrigerator Service Access Compartment

    SECTION 4 – APPLIANCES AND SYSTEMS To Open: 1. Use a screwdriver or coin to turn the latch knobs to the vertical position as shown. Refrigerator Access Door Latches • Gas- Refrigerator will operate on gas from the propane tank if the main valve is open and the 2.

  • Page 43: Microwave Oven

    SECTION 4 – APPLIANCES AND SYSTEMS Unlike homes, the amount of oxygen supply is To Light Range Top Burners • Turn the desired burner knob to HI LITE position limited due to the size of the recreational vehicle, • Immediately spin the IGNITOR knob clockwise and proper ventilation when using the cooking at least one full turn to light the burner appliances avoids dangers of asphyxiation.

  • Page 44: Range Hood

    SECTION 4 – APPLIANCES AND SYSTEMS RANGE HOOD -If Equipped The range hood vent draws cooking odors and airborne grease particles into the filtration grid and either recirculates the air or vents it to the outside of the coach, depending on model. A light on the underside of the hood provides illumination for cooking and food preparation.

  • Page 45: Water Heater - Gas

    SECTION 4 – APPLIANCES AND SYSTEMS The propane level is registered by a sending WATER HEATER – GAS unit on the tank. The gauge mounted on the side of the tank will give a more accurate indication of NOTE: Read the Water Heater Operating Guide actual tank level if needed.

  • Page 46: Water Heater - Gas/ Electric

    SECTION 4 – APPLIANCES AND SYSTEMS WATER HEATER - GAS/ ELECTRIC –If Equipped (with Motoraid water heating system) The gas/electric water heater has a dual power feature. It can operate from propane gas or 120- volt house current; or it can use both at the same time for quicker recovery at times when you are using a lot of hot water.

  • Page 47: Motoraid Water Heater

    SECTION 4 – APPLIANCES AND SYSTEMS MOTORAID WATER HEATER –If Equipped The motoraid uses heat from the chassis engine cooling system to heat water in the water heater while driving. Hoses are routed from the engine to a heat exchanger surrounding the water heater tank.

  • Page 48: Propane Gas Furnace

    SECTION 4 – APPLIANCES AND SYSTEMS Lift handle straight out to open P-T valve Thermostat Switch Temp Selector when water heater is cold* • Move to Heat or • Press up or 4. Let the handle of the P-T valve snap shut. Gas position for down to select furnace operation...

  • Page 49: Heat Pump

    SECTION 4 – APPLIANCES AND SYSTEMS Further Information temperatures begin to reduce the efficiency of the heat pump. The heat pump will not operate when Please see the furnace operating instructions the outside temperature falls below 36 degrees F. provided in your InfoCase for further information, including operating precautions, To operate the heat pump: and periodic maintenance.

  • Page 50: Energy Management System (Ems)

    SECTION 4 – APPLIANCES AND SYSTEMS a specific area of the coach or to route REAR AIR CONDITIONER cool air away from a specific area. If too POWER SELECTOR SWITCH many vents are closed, however, it can cause the air conditioner unit to shut –If Equipped down, particularly in high humidity (models with 2 roof air units and 30-amp...

  • Page 51: Furnace-A/C Thermostat Operation Chart

    SECTION 4 – APPLIANCES AND SYSTEMS FURNACE-A/C THERMOSTAT OPERATION CHART The following chart shows the system functions with the “Heat/Cool” thermostat. Disregard references to heat functions when using the “Cool Only” thermostat in the rear bedroom. X = Switch Position O = Switch position does not matter or is inactive for this feature FAN MODE FAN SPEED...

  • Page 53: Propane Gas

    SECTION 5 – PROPANE GAS PROPANE GAS SUPPLY The propane gas system supplies fuel for the gas range/oven, water heater, furnace, and refrigerator (while in gas mode). When used and handled properly, this system is safe and economical and provides modern living conveniences wherever you travel.

  • Page 54: Safe Use Of The Propane Gas System

    SECTION 5 – PROPANE GAS phone directory yellow pages for locations of local propane gas refilling stations or bulk DAN G E R dealerships. NOTE: If you travel outside the U.S. with your DO NOT FILL CONTAINER TO MORE motor home, you may find butane or THAN 80 PERCENT OF CAPACITY.

  • Page 55: Propane Gas Warnings And Precautions

    SECTION 5 – PROPANE GAS • Exercise caution at all times. Be familiar with PROPANE GAS WARNINGS the distinctive odor of propane gas. If a leak is AND PRECAUTIONS suspected, turn off the supply valve immediately. Have the propane gas system It is illegal for vehicles equipped with propane checked by your dealer or other qualified tanks to travel on certain roadways or through...

  • Page 56: Propane Gas Pressure Regulator

    SECTION 5 – PROPANE GAS WARNING WARNING Propane cylinders shall not be placed or Visually inspect the pressure regulator stored inside the vehicle. Propane vent periodically for blockage by cylinders are equipped with safety accumulated debris or insect nests, etc. devices that relieve pressure by Vent obstruction could result in excessive discharging propane to the atmosphere.

  • Page 57: Propane Vaporization In Cold Weather

    SECTION 5 – PROPANE GAS This means that in extremely cold weather when a large volume of gas is being used by the furnace for heating, it is possible to experience a loss of gas pressure. At first, this problem may appear to be caused by an empty tank or a regulator freeze-up, but is actually caused by failure of the liquid gas to vaporize as fast as it is needed by the furnace.

  • Page 59: Electrical

    SECTION 6 – ELECTRICAL Your coach is equipped with an electrical the power converter automatically changes a system consisting of two separate voltages: portion of the 120-volt current to 12-volt DC current. All equipment in the motor home that is •...

  • Page 60: Connecting The Power Cord

    SECTION 6 – ELECTRICAL be used is designed to mate with the prongs of the power cord plug, the electrical connection can be expected to carry rated load. Connecting the Power Cord To connect to an external source, remove the cord from the utility compartment and plug it into a suitable power outlet to provide external power to the coach and converter/charger system.

  • Page 61: Power Center

    SECTION 6 – ELECTRICAL mate with the three prongs on the power cord plug, the electrical connection can be expected to carry rated load. NOTE: Always keep service access passage closed while utility connection is not in use. Park Fuses or Breakers Most campgrounds are equipped with a fuse or circuit breaker at the receptacle.

  • Page 62: Circuit Breakers - House 120-Volt Ac

    SECTION 6 – ELECTRICAL Charging Section component itself. When an overload or short develops, the breaker will open preventing The converter charges house batteries while damage to the system. 120-volt external power is connected. The Shut off the equipment (example: roof air converter will automatically “sense”...

  • Page 63: Ground Fault Circuit Interrupter

    SECTION 6 – ELECTRICAL GROUND FAULT CIRCUIT ELECTRICAL GENERATOR – INTERRUPTER 120-VOLT –If Equipped Bath, galley, and exterior outlets are connected to a GFCI (Ground Fault Circuit Interrupter), which is an extremely sensitive WARNING circuit breaker that will help to protect against severe electrical shock if a ground fault develops.

  • Page 64: Electrical System - House 12-Volt Dc

    SECTION 6 – ELECTRICAL Automatic Power Transfer Switch Operation Warnings and Cautions (available with 50-amp service only) -If Equipped WARNING Whenever the generator is needed, an automatic power transfer system automatically switches the household electrical system to the The exhaust of all internal combustion generator 10 seconds after the generator is engines contains carbon monoxide (CO).

  • Page 65: House Battery Disconnect Switch

    SECTION 6 – ELECTRICAL Chassis Battery NOTE: Some electronic displays and memory functions may need to be reset after The chassis battery is used to operate the power has been reconnected. engine starter and automotive accessories and controls found on the instrument panel. The See also “Battery Care”...

  • Page 66: Battery Care

    SECTION 6 – ELECTRICAL The two best defenses against sulfating and insufficient charge are to: 1. Turn off the House/Coach Battery Disconnect (House/Coach Batt) switch to avoid parasitic discharge (the trickle discharge caused by directly connected components like propane gas detectors or digital clock displays, etc.) 2.

  • Page 67: Circuit Breakers And Fuses - House 12-Volt

    SECTION 6 – ELECTRICAL • Neutralize corrosion buildup or acid film on top of battery by washing with a baking soda/ WARNING water solution. Rinse with clear water. NOTE: Make sure vent caps are on securely to prevent baking soda solution from To prevent wiring damage, it is essential when replacing the cables on the battery, entering the battery and contaminating...

  • Page 68: Battery Charge Meter

    SECTION 6 – ELECTRICAL House 12V Breakers -Typical View Battery Charge Meter See related item under “Systems Monitor Panel” in Appliances section. Battery Boost Switch See Driving Your Motor Home section for information on the Battery Boost Switch. 6-10...

  • Page 69: Plumbing

    SECTION 7 – PLUMBING FRESH WATER SYSTEM The fresh water system provides water to the galley sink, shower, bathroom lavatory, toilet, and water heater. Water may be supplied by either of two sources: • a fresh water tank and water pump located within the motor home;...

  • Page 70: Water Pump

    SECTION 7 – PLUMBING 2. Turn Fresh Water Valve to Normal position Water pressure regulators are commonly and turn the water pump switches OFF. available at most RV dealerships and many large retail discount or home supply centers. WATER PUMP When your coach is not connected to a city water supply, water is supplied from the fresh water tank by a water system demand pump.

  • Page 71: Disinfecting Your Fresh Water System

    SECTION 7 – PLUMBING 2. Turn water pump switch to “OFF” position. 3. Fill water tank. 4. Open all faucets, hot and cold. 5. Turn on pump switch. 6. Close each faucet as it begins to deliver a steady stream of water (close cold water first). Leave hot water faucets on until they also deliver a steady stream of water.
  • Page 72 SECTION 7 – PLUMBING water fill to add disinfecting solution to the tank. 2. Fill the tank completely, then open each faucet These filters are commonly available at RV in the coach and run the water until a distinct supply stores. odor of chlorine can be detected in the water discharged.

  • Page 73: Shower Hose Vacuum Breaker

    SECTION 7 – PLUMBING will result in a 6.7 ppm level of chlorine, which should kill harmful bacteria and slime- forming organisms. • Chlorine may be removed from drinking water by the cold water filter at the galley faucet (if equipped) or by installing an activated carbon water purifier at the galley sink cold waterline or a separate drinking water faucet with filter.

  • Page 74: Waste Water System

    SECTION 7 – PLUMBING See winterizing instructions at the end of this section to prepare the toilet for storage in freezing conditions. Further Information See the toilet manufacturer’s operation information in your InfoCase for complete operating, care, and maintenance information. WASTE WATER SYSTEM (Holding Tanks) Holding Tank Dump Valves (Typical)

  • Page 75: Waterline & Tank Drain Valves

    SECTION 7 – PLUMBING Using On-Site Sewer Hook-Ups The drain hose may remain attached to the D R A I N D R A I N dump outlet and be routed out the bottom of the C L O S E C L O S E compartment while the motor home is parked and connected to an on-site sewage hook-up.

  • Page 76: Water Heater Bypass Valve

    SECTION 7 – PLUMBING WATER HEATER BYPASS VALVE Your coach may be equipped with a water heater bypass valve for easier winterization of water lines using RV antifreeze. See table at the end of this section for valve location. Turn the handle as shown to either bypass or flow through the water heater.
  • Page 77 8. Turn off the water heater power switch before to force air through the system. A “blow-out” draining the water heater tank to avoid ® plug can be purchased at any Winnebago damage to the heating element. Drain the ® Itasca dealer.
  • Page 78 SECTION 7 – PLUMBING 12. Turn air pressure off and disconnect water purge adapters. Recap the city water See instructions for removal from storage in connection to avoid contamination by dirt or Maintenance Section. insects. Method 2 - Antifreeze Fill After Disconnecting Air Pressure Procedure 13.
  • Page 79 SECTION 7 – PLUMBING Set Up Winterization Valves 10. Turn the winterization valve so it points toward the waterline to the pump. This will 2. Turn water heater bypass valve to BYPASS stop the flow from the suction tube and revert position.

  • Page 80: Winterizing Optional Appliances

    SECTION 7 – PLUMBING Drain Appliances 2. Unscrew the water supply line from the bottom of the water inlet valve and drain any 16. At this time, if your coach is equipped with an water left in the line. This connection is optional refrigerator ice maker, dishwasher, or located in the refrigerator service washer/dryer, the waterlines for these...
  • Page 81 SECTION 7 – PLUMBING To use washer/dryer again: 2. Close the door. Advance the Program Selector knob to a SPIN position. Flush antifreeze from the waterlines, then 3. Press ON/OFF Button (IN). Wait 1-2 minutes. 1. Reconnect the water inlet hoses to the 4.

  • Page 82: Water System Drain Valve Locations

    SECTION 7 – PLUMBING WATER SYSTEM DRAIN VALVE LOCATIONS Model System Drain Valve Locations Waterlines Open exterior shower faucet and lay shower head on ground. Also place the tip of your finger inside the city water connection and gently press the backflow valve (small “button”...
  • Page 83 SECTION 7 – PLUMBING Waterlines Inside utility compartment in passenger side rear cargo compartment and open exterior shower. See photo below. Water Tank Large yellow-handled valve in utility compartment. See photo below. Water Heater Drain plug on outside of coach, behind service door. Use socket to remove drain plug.

  • Page 85: Entertainment

    SECTION 8 – ENTERTAINMENT FRONT TV IGNITION SWITCH DVD PLAYER INTERLOCK –If Equipped If your coach is equipped with a front overhead TV, it is plugged into a special electrical outlet with a built-in ignition switch interlock. The device allows the front overhead TV to operate only when the ignition key is in the Off or Accessory positions.

  • Page 86: Flip-Down Screen Video Players

    SECTION 8 – ENTERTAINMENT Play DVD FLIP-DOWN SCREEN VIDEO • Insert DVD into player. DVD will begin to PLAYERS load automatically. TV screen will typically (Rear Bunk models only) show “READING” or LOADING”. –If Equipped • The DVD may load directly to the main title/ menu screen or it may begin to play previews.

  • Page 87: Audio-Video Selector

    SECTION 8 – ENTERTAINMENT 12-Volt Master Power • Insert the CD label side down (facing you) into the slot on the side of the player. The • The Video Players operate on player will automatically switch to proper 12-volt DC current. Turn on the mode to play audio or video CD.

  • Page 88: Bedroom Tv 12-Volt Master Power Switch

    SECTION 8 – ENTERTAINMENT Audio-Video Selector Bedroom Audio/Video (Located in passenger side overhead cabinet) Connection Plate -Typical View -Typical View BEDROOM TV 12-VOLT ELECTRICAL INVERTER MASTER POWER SWITCH 300-Watt DC-to-AC –If Equipped –If Equipped The 12-volt TV master power switch lets you The inverter changes 12-volt DC automotive turn off the bedroom TV “instant on”...

  • Page 89: Electrical Inverter

    SECTION 8 – ENTERTAINMENT 600-Watt DC-AC Power Inverter 300-Watt DC-AC Power Inverter • Turn Inverter switch On to use inverter power. • Turn Inverter On to operate TV. • Inverter Power indicator will light when inverter is • Low Battery indicator will light if 12V house operating.

  • Page 90: Tv Signal Amplifier

    SECTION 8 – ENTERTAINMENT WARNING CAUTION Never allow the antenna to touch To avoid equipment damage, always electrical power lines or any other align directional handle to DOWN position electrical wires. before lowering. Never partially raise or lower antenna. Antenna must be raised fully up into operating position or lowered Raising Antenna to Operating Position fully down into travel position.

  • Page 91: Cable Tv Hook Up

    A second connection may be included in an Panel to connect the TV to the Satellite overhead cabinet in the bedroom for the rear TV system. (if equipped.) ® See your authorized Winnebago Industries dealer for proper installation and sealing of roof mounted components.

  • Page 92: Exterior Entertainment Center

    SECTION 8 – ENTERTAINMENT Further Information Please read the manufacturer’s operating information in your InfoCase for operation of Radio/CD player. Digital Satellite Dish Control (located on ceiling) Further Information See the Digital Satellite System owner’s manual in your InfoCase for operation and antenna dish aiming instructions.

  • Page 93: Furniture And Softgoods

    SECTION 9 – FURNITURE AND SOFTGOODS When the vehicle is parked, you can unscrew LOUNGE CHAIR – SWIVEL the knob and remove the clamp to position the GLIDER chair away from the wall. –If Equipped This chair is not equipped with a seat belt and is not intended for seating while the coach is in motion.

  • Page 94: Sleeping Facilities

    SECTION 9 – FURNITURE AND SOFTGOODS Dining Table Chairs -Typical View You can unscrew the knob and remove the clamp to position the table wherever you desire in 1. Push dining table chairs against opposite sides the living area of the coach while the coach is of table.

  • Page 95: Sofa/Bed Conversion

    SECTION 9 – FURNITURE AND SOFTGOODS SOFA/BED CONVERSION Sofa to Bed Lift the front edge of the sofa seat upward and pull outward from the wall while gently pushing downward on the backrest until the cushions lie flat. The bed is now ready for use. Bed to Sofa Push the front edge of the seat toward the wall while lifting upward on the backrest until the sofa...

  • Page 96: Sofa Air Bed (Comfort Sofa Sleeper)

    SECTION 9 – FURNITURE AND SOFTGOODS Reverse steps to convert back into dinette seating. 3. Rotate the lever lock (located on the bottom right-hand side of the sofa air bed) clockwise SOFA AIR BED (COMFORT to release the locking mechanism (which is SOFA SLEEPER) required to unfold the bottom section of the sofa air bed).
  • Page 97 SECTION 9 – FURNITURE AND SOFTGOODS Power Button Set Up Take Down Button Button (to inflate (to deflate air mattress) air mattress) Air Mattress Hand Control 5. Unfold the air mattress so it is covering the (Located on the back side of the sofa) sofa bed.
  • Page 98 SECTION 9 – FURNITURE AND SOFTGOODS • To increase the firmness of the air mattress, press and hold the FIRM button (on the preferred chamber located on the hand control). When the button is released, the pump will turn off. •...

  • Page 99: Day/Night Pleated Blinds

    SECTION 9 – FURNITURE AND SOFTGOODS The tension cords are attached to spools at the lower corners of the blinds as shown in the following photo. Further Information For further operating instructions, cautions, and maintenance care, see the manufactuer’s user guide included in the air mattress carrying bag.

  • Page 100: Wood Furniture And Cabinetry

    People are drawn to the natural beauty of and the wood is considered part of the natural ® wood. At Winnebago Industries , our craftsmen aging process and is not to be considered defect work with the art found in each piece of wood to or damage.

  • Page 101: Slideout Rooms And Leveling

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING To Release SLIDEOUT ROOM TRAVEL • Press and Hold the UNLOCK side of the LOCKS - ELECTRIC Slideout Room Lock switch for about 7 –If Equipped seconds. (You may be able to hear the lock motor sound stop).

  • Page 102: Slideout Room Travel Lock

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING NOTICE Release and remove Slideout Prop-Lock Rod before attempting to extend slideout room. Damage to the vehicle will result if this is not done. Position and secure Prop-Lock before driving vehicle. See following instructions. To Release Lock Rod: Slideout Lock Drain Line •...

  • Page 103: Slideout Room Operation - Electric

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING Master Keylock SLIDEOUT ROOM OPERATION A master keylock switch is located near the – ELECTRIC power switch for the front slideout room. This keylock must be turned on to provide power to the slideout control switches. WARNING Your motor home may have more than one slideout room.
  • Page 104 SECTION 10 – SLIDEOUT ROOMS AND LEVELING SLIDEOUT ROOMS so the engine • Insert the Safety Lock key and turn to activate alternator can provide maximum power slideout room control switch. for proper operation of the slideout • Press the Slideout Room “EXTEND/OUT” mechanisms.

  • Page 105: Slideout Room - Extreme Weather Precaution

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING by raising both right side jacks to let excess water flow away from the rooftop weather seal and toward the outside of the slideout roof. Retract the slideout slowly, starting and stopping to allow water to drain off room cover.
  • Page 106 SECTION 10 – SLIDEOUT ROOMS AND LEVELING Both methods listed below are intended as a Light will flash fault means to retract the room to prepare the coach for Light will flash if code if system travel to the nearest authorized service center. park brake not set malfunctions Manual Mode...

  • Page 107: Slideout Emergency Retraction - Electric

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING SLIDEOUT EMERGENCY Light will flash fault RETRACTION – ELECTRIC Light will flash if code if system park brake not set malfunctions (Front Slideout Room) -If Equipped Crank-In Procedure If the slideout mechanism is malfunctioning and will not retract using the buttons, you will need to manually crank the room in to the travel position.

  • Page 108: Slideout Emergency Retraction - Electric

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING NOTE: It may be necessary to move the crank SLIDEOUT EMERGENCY handle from side to side slightly to fit RETRACTION - ELECTRIC onto the shaft. • Each crank will only move the arm that it is (Front Slideout Room) inserted into, so you will need to alternate -If Equipped...

  • Page 109: Slideout Emergency Retraction - Bedroom

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING • Use a 3/4” socket and ratchet wrench on the motor gearbox shaft to crank the room in or out as needed. Crank both sides of the room alternately and equally to avoid wedging the room.

  • Page 110: General Slideout Care

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING LEVELING SYSTEM –If Equipped The hydraulic leveling system makes selecting a parking site easier and faster by reducing the effect of uneven ground. Hydraulic jacks raise the affected low corners of the coach to make leveling “set up” faster and easier for you.
  • Page 111 SECTION 10 – SLIDEOUT ROOMS AND LEVELING WARNING • Keep all people clear of the coach while the leveling system is operating. • When extending the rear stabilizers, do not lift the wheels beyond ground contact. This makes it possible for the Auto Level Switch vehicle to roll unexpectedly forward (or (Located near entrance door)

  • Page 112: Checking Hydraulic Oil Level

    RV into an oil in the reservoir, which could lead to ® authorized Winnebago Industries dealership for pump failure or other problems. a complete leveling system inspection before using again.
  • Page 113 SECTION 10 – SLIDEOUT ROOMS AND LEVELING Hydraulic Oil Reservoir -Typical View NOTE: Overfilling the hydraulic reservoir can cause leakage of oil through the breather cap. Hydraulic Fluid Recommendation ® ® Dexron III or Mercon V automatic transmission fluid is recommended for use in your leveling system.

  • Page 115: Maintenance And Storage

    • Have the sealant replaced if you notice any of attention. Delaying these repairs may allow water the above. Your local Winnebago Industries leakage and result in damage to interior ceiling dealer has the correct and necessary parts and and body panels, upholstery, etc., which is not experience to help you maintain your sealants.

  • Page 116: Exterior Automotive Paint Finish

    SECTION 11 – MAINTENANCE AND STORAGE weight to the vehicle. This, in effect, reduces the initial 60-day cure stage, a coat of wax or amount of cargo you can carry and remain within polish can help protect the surface from these GVWR and GAWR limits.
  • Page 117 SECTION 11 – MAINTENANCE AND STORAGE Bug Removal to clean heavy road films on semi trailers and are often dirty. They are not • Rinse the loose debris off with water and designed for custom painted RV’s and allow the remaining residues to soak and they will scratch the clearcoat finish.

  • Page 118: Care Of Appliques And Decals

    SECTION 11 – MAINTENANCE AND STORAGE is subjected to various twisting and flexing forces • Fuel or antifreeze spilled on appliques or caused by routine cornering and turning, and by decals should be rinsed off immediately with uneven road surfaces, such as bumps, potholes, water.

  • Page 119: Interior Soft Goods

    SECTION 11 – MAINTENANCE AND STORAGE • Kerosene or gasoline • Naphthalene WARNING • Pine-type household cleaners Do not use cleaners containing the following When cleaning upholstery and fabric, do products, compounds ,or solvents. These not use lacquer thinner, nail polish products will damage the finish.

  • Page 120: Ceiling Fabric Care

    SECTION 11 – MAINTENANCE AND STORAGE Most commercially available carpet and upholstery cleaners will do an excellent job UltraLeather Cleaning Chart removing stains. From time to time, additional Detergent/ Cleaner/ cleaning methods may need to be used to remove Type of Stain Water Degreaser stubborn or difficult stains.

  • Page 121: Cabinetry - Cleaning

    SECTION 11 – MAINTENANCE AND STORAGE The following cleaning chart is provided as a guideline for care and cleaning of ceiling fabrics used in your coach. CEILING FABRIC STAIN REMOVAL Type of Stain Cleaning Agent How to Remove Mustard Dry-Clean Solvent Scrub-Soak-Blot Dry Ketchup* High Strength Detergent...

  • Page 122: Tables And Countertops

    SECTION 11 – MAINTENANCE AND STORAGE Hard-to-Remove Food and Beverage Vinyl simulated wood panels may be cleaned Residue with a mild, water-based cleaner and a soft cloth. Do not use solvents on vinyl wood panels. For most stubborn stains, fill the sink about one quarter full with a 50/50 solution of bleach NOTE: Many cabinetry and furniture items and water.

  • Page 123: Doors And Windows

    SECTION 11 – MAINTENANCE AND STORAGE Rinse all food, beverage, or cosmetic residue DOORS AND WINDOWS from the sink as soon as possible. Some residues, if left to sit in the sink, may require the use of Windows may be periodically cleaned with a detergent or a mild liquid or gel-type kitchen good quality glass cleaner or mild soap solution surface cleaner.

  • Page 124: Vehicle Storage - Removal

    SECTION 11 – MAINTENANCE AND STORAGE can lose electrolytic fluids and become 4. Check cabinet and door hinges. Lubricate damaged from continuous charging with penetrating oil, if necessary. without periodic use. We recommend 5. Close all faucets and drain valves that are following regular battery inspection and open.
  • Page 125 SECTION 11 – MAINTENANCE AND STORAGE quickly and easily applied. Appropriate compounds are available from your dealer. See Sealants – Recommended Application page in the Supplement Manual provided in your InfoCase. Also inspect weather seals around doors, etc., and if necessary, have a dealer replace immediately.

  • Page 126: Coach Maintenance Chart

    SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Propane Gas System Have propane gas system checked for leaks Pressure Regulator - inspect and adjust if needed Check propane tank condition, mounting, and fittings...
  • Page 127 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Safety Equipment Check operation of the following items: Headlights, Taillights, and Marker Lights Turn Signals...
  • Page 128 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Sealants Inspect (see “Sealants”...

  • Page 129: Miscellaneous

    SECTION 12 – MISCELLANEOUS NOTE: We recommend that you dump all LOADING THE VEHICLE holding tanks before traveling to avoid carrying unnecessary weight. NOTE: Your motor home’s load capacity is designated by weight, not by volume, so you cannot necessarily use all available space when loading your motor home.
  • Page 130 SECTION 12 – MISCELLANEOUS Corner Weighing (Side-to-Side) You will first drive only your front wheels onto the scale pad, then drive ahead so that the The most accurate method of weighing a whole vehicle is on the scale, then finally pull off motor home is to weigh each “corner”...

  • Page 131: Car Or Trailer Towing

    SECTION 12 – MISCELLANEOUS axle is 12,000 lbs., then the load on each rear dual listed Gross Weight Ratings. See “Vehicle set (left rear duals or right rear duals) should not Certification Label” in the Introduction section exceed 6,000 lbs. for information on gross weight ratings.

  • Page 132: Trailer Wiring Connector

    SECTION 12 – MISCELLANEOUS Before descending a steep or long grade when TRAILER WIRING towing a trailer, reduce speed and shift into a CONNECTOR lower gear to control vehicle speed. Avoid prolonged or frequent application of brakes Your coach is pre-wired for trailer or car which could cause overheating and brake failure.

  • Page 133: Entry Step - Electric

    350 vehicle drive train: engine and cooling systems, lbs. All Winnebago Industries models transmission, drive line, drive axle, and others. equipped with a Class IV hitch have a...

  • Page 134: Windows

    SECTION 12 – MISCELLANEOUS Stationary Extended Mode - Step Switch OFF (Step Remains Extended) With the Step power switch in the OFF position, the step will extend when the screen door is opened and will stay extended whether the door is opened or closed. NOTE: The step switch is “locked”...

  • Page 135: Power Roof Ventilator

    SECTION 12 – MISCELLANEOUS Vertical Slider Windows Vertical windows have spring-loaded catches on both sides of the window that pop out to hold • Pull out the lever on the crank-out handle and the window in its fully raised position. Press the begin cranking out the window counter- catches outward toward the frames while clockwise to the position desired.

  • Page 136: Manual Awning

    SECTION 12 – MISCELLANEOUS Further Information Manual Dome Fuse Fan Speed See the power ventilator manufacturer’s Crank Knob Selector operating instructions supplied in your InfoCase for further instructions, care, and cleaning information. MANUAL AWNING –If Equipped Further Information For complete operating instructions, refer to the manufacturer’s information provided in your InfoCase.

  • Page 137: Tool And Ladder Storage

    SECTION 12 – MISCELLANEOUS Before Using the Ladder • Inspect the ladder to make sure it is not damaged. Never use a damaged ladder. • Keep the rungs of the ladder clean and dry while in use. Never use the ladder when it is raining, snowing, or icy.

  • Page 138: Humidity And Condensation

    SECTION 12 – MISCELLANEOUS Humidity and Condensation Moisture condensing on the inside of windows is a visible indication that there is too much humidity inside the coach. Excessive moisture can cause water stains or mildew, which can damage interior items such as upholstery and cabinets.
  • Page 139 INDEX 2010 New Vehicle Limited Warranty ..1-8 Electrical ............2-5 About this Manual ........1-1 Electrical Cautions ........6-1 Air Conditioner/Heater – Electrical Generator – 120-Volt ....6-5 Automotive (Dash) ........3-8 Electrical Inverter ........8-4 Audio-Video Selector ........8-3 Electrical Inverter ........
  • Page 140 Index Leveling System ........10-10 Roof ............11-1 Lights ............3-12 Roof and Ladders ......... 2-8 Loading ............2-5 Roof Ladder ..........12-9 Loading the Vehicle ........12-1 Safe Use of the Propane Gas System ... 5-2 Lounge Chair – Swivel Glider ..... 9-1 Safety Messages Used in this Manual ..
  • Page 141 Index Vehicle Certification Label ......1-4 Vehicle Storage – Preparation ....11-9 Vehicle Storage – Removal ..... 11-10 Waste Water System ........7-6 Water Heater – Gas ........4-5 Water Heater - Gas/ Electric ......4-6 Water Heater Bypass Valve ......7-8 Water Pump ..........

Table of Contents

Save PDF
