5.6 ARMRESTS

5.6.1 Armrest height
A
Adjust the height of the armrests by turning the knob
or Allen key screw (A), setting the required height and
then re-tightening the knob/screw.
Be aware not to trap your fingers between the
armpad and the sidesupport when you adjust
the armrest height.
5.4.2 Autolock for armrests
The armrests have an auto-lock to prevent involuntary
movement or detachment. Press the button (B) on
the spring to release before removing or adjusting
the armrest.
Azalea
R
5.6.2 Armrest depth
B
You can also adjust the depth of the armrest pad.
Loosen the knob (C), set the pad in the required
position and re-tighten the knob.
C
