5.4 CARER-OPERATED ANGLE ADJUST-
MENT
The wheelchair is equipped with carer-operated controls. You can adjust the angle of the backrest forwards
or backwards and tilt the whole seat unit including the backrest. These two functions can either be controlled
manually or electrically.
Be careful when adjusting the angle of the backrest so that the assistant or user do not trap fingers
between the backrest and the armrest.
5.4.1 Backrest angle adjustment
Use the yellow (A) lever on the left hand side to
angle the backrest.
Press upwards while you angle the backrest to the
desired position,
Release the lever.
16
A
5.4.2 Tilt adjustment
B
Use the green lever (B) on the right hand side to
tilt the seat unit (seat and backrest).
Press upwards while you tilt the seat unit to the
desired position,
Release the lever.
Azalea
