VBOX 3i User Guide

Logging

The VBOX 3i has three Logging modes that are selected and configured via VBOXsetup with the supplied VBOXTools software
Logging Modes
 Log Continuously:
With „Log Continuously‟ ticked the VBOX will log data, regardless of movement.
 Log Only when moving:
Without „Log Continuously‟ ticked then the VBOX will only log data to the CF card when it detects speed >0.5Km/h.
 Advanced:
The advanced logging option on the VBOX 3i allows any of the logged data channels to be used to trigger the logging on the VBOX.
This is selected and configured through VBOXsetup of the supplied VBOXTools software.
This facility allows a threshold value to be set as either > or < so that the logging will start or stop when a data value is exceeded or not.
Multiple Data channels can be combined in a Boolean „OR‟ manner to control the logging.
28/08/2013
Page 12 of 46
