VBOX 3i User Guide
Outputs
CAN Bus
Bit rate
Identifier type
Data available
Analogue
Voltage range
Default setting *
Accuracy
Update rate
Inputs
CAN Bus
Racelogic modules
External CAN Bus
Analogue
Number Channels
Input range
Channel Sample order
Digital
Brake/Event Trigger
On/Off Logging control
28/08/2013
125Kbits, 250Kbits,
500Kbits & 1Mbit
selectable baud rate
Standard 11bit 2.0A
Satellites in View, Latitude, Longitude, Velocity, Heading, Altitude, Vertical velocity, Distance, Longitudinal acceleration & lateral
acceleration, Distance from trigger, Trigger time, trigger Velocity
Digital
0 to 5Volts DC Frequency range
Velocity Default setting *
0.0125Volts per Km/h (0
to 400Km/h)
0.1 Km/h
100Hz Accuracy
Update rate
* The range settings can be adjusted by the user in software
Up to 32 channels from any combination of ADC02, ADC03, FIM02, TC8, Yaw sensor or CAN01. Limited to 16 with the Kalman
Filter enabled
16 Channels of user definable CAN signal from external bus. Eg; vehicle CAN bus
Can load signal data from industry standard DBC database file.
4 Resolution
±50v DC Accuracy
Synchronous
10ns resolution
Remote log control from hand-held switch
DC to 44.4Khz
25Hz per Km/h (0 to 400Km/h)
90 pulses per metre
0.1Km/h
100Hz
24 bit
400 μV
Page 39 of 46
