LEDs

VBOX Touch has 4 LEDs above the display. These can flash in different colours and different frequency patterns

depending on the process being performed. You can learn more about the behaviour of the LEDs on VBOX Touch here.

The

red

Record Icon will show when the unit is logging

data to the SD card.

If the icon appears white after you have initiated

logging, it means that the unit is primed for logging and

is in the process of synchronising the internal real-time

clock (RTC) to GPS time. The logging will not start until

this synchronisation process is complete.
