Eclipse User Manual

Operation

...don't touch the sides!
You remember "Operation" - the childhood game where you pull plastic bones and other parts
out of a little cardboard man? No? Oh well...

Mounting and Handling

Normally, you should have the Eclipse rack mounted in a standard 19-inch rack. If you take it on the road,
support it from the rear as well. Keep the Eclipse well ventilated, dust-free, dry, and, like Little Bear's
porridge, neither too hot nor too cold. Don't play catch with the Eclipse or use it as a bat. Pat the Eclipse
gently and whisper sweet nothings of affection in its direction before powering it down for the night...

Memory Cards

The Eclipse accepts CompactFlash cards of all memory capacities. All functions that work with internal
memory also work with memory cards. In addition to increasing the number of programs you can store,
memory cards allow you to take your programs to a friend's Eclipse or to trade your programs for can-
dies.
To insert a memory card, well, just insert it until it stops. To remove a memory card, just pull it out (but be
sure that the yellow light isn't illuminated when you do so!). It's possible to load a program from a
BUSY
memory card and then remove the memory card – the program will still run. The card only needs to be in
 see page 54 for formatting information
place for such functions as loading, saving, updating, removing, and so forth.
While more resilient than removable media of yesteryear, you should still treat your CompactFlash cards
with respect, lest bad things happen. Don't spill on them, don't shock them, don't leave them on the dash
under hot sun, and on and on. CompactFlash cards do not need batteries.

The Display Brightness and Click Features

DISP (BRIGHT)
Press page 2 to adjust the brightness. adjusts the
SETUP
(AUTODIM)
brightness of the display in sixteen increments, while re-
duces the brightness after a set period of inactivity to prolong the display's
(AUTODIM) 5 120
life. can kick in after to minutes of inactivity, or it can
be turned off. After the screen autodims, it can be brought back to full
brightness by pressing a button or turning the knob.
It's like sleep mode for
your computer's display!
DISP CLICK
Press page 2 to adjust the click features. The knob
SETUP
(KNOB) On
will click when turned if you adjust to , buttons will click
(KEYS) On
when pushed if you adjust to , and the tempo will click if you
(TEMPO) On
adjust to .
Click, click, click. Such fun...
Eclipse User Manual Page 20 of 66 Release 4.0.1
