Sample Rates

96kHz, 88.2kHz, 48kHz, 44.1kHz or external.

Frequency Response

Sample Rate 44.1kHz
+0/-0.1dB 20Hz-20kHz
+0/-3.0dB 5Hz-21kHz

Digital Inputs/Outputs

2 AES and 2 S/P DIF at 44.1-96kHz. AES relay bypass at power down.

Analog Input (XLR Balanced Inputs)

Impedance >20kOhm, bridging
Full Scale Input
26dBu
Level
Dynamic Range >100dB
Signal to Noise >100dB, A-weighted
Ratio
THD+N <0.002% @ 1kHz, -3dBFS
Crosstalk <-100db @ 20 Hz to 20kHz, -1dBFS

Analog Output

Impedance <50Ohm
Full Scale Output 26dBu
Level
Dynamic Range >110dB
Signal to Noise
>110dB, A-weighted
Ratio
THD+N <0.002% @ 1kHz, -3dBFS
Crosstalk <-100db, 20 Hz to 20kHz, -1dBFS

Remote Control Inputs

Up to 2 foot pedals (or 0-5V control inputs), or 6 footswitches, or combination.

MIDI Connections

5 pin DIN output and thru.
7 pin DIN input with output capability and external power jack.
Eclipse User Manual
Eclipse User Manual

Electrical Specifications

48kHz
20Hz-22kHz
5Hz-23kHz
Page 58 of 66
88.2kHz 96kHz
20Hz-41kHz 20Hz-44kHz
5Hz-42kHz 5Hz-46kHz
