EXTERNAL
page 3
SETUP
EXT#1
"connections,"
First, press page 3
SETUP
ler you want to "connect" with
(MONITOR)
. Our choices are:
off
No external controller will be connected.
low,mid,high
Fixed values for testing
pedal 1, 2
The input from the pedals at the rear panel foot pedal jacks 1 & 2.
tip 1, 2 tip
is fully modulated when a switch connected between tip and sleeve of the rear foot
pedal jack is closed.
ring 1, 2 ring
foot pedal jack is closed.
tip & ring 1, 2 tip & ring
switch connected between them and the sleeve of the rear foot pedal jack is closed.
mod wheel
MIDI control message 1 - typically assigned to the mod wheel on a MIDI keyboard.
breath con
MIDI control message 2 - typically assigned to the breath controller on a MIDI key-
board.
foot con
MIDI control message 4 - typically assigned to the foot controller on a MIDI keyboard.
damper
Triggers when a damper control message (MIDI control message 64) is received with
damper = 1.
portamento
Triggers when a portamento control message (MIDI control message 65) is received
with portamento = 1.
sostenuto
Triggers when a sostenuto control message (MIDI control message 66) is received with
sostenuto = 1.
soft
Triggers when a soft control message (MIDI control message 67) is received with
soft = 1.
hold 2
Triggers when a "hold 2" control message (MIDI control message 69) is received with
"hold 2" = 1.
volume
MIDI control message 7 - typically assigned to volume changes.
balance
MIDI control message 8 - typically assigned to balance.
pan
MIDI control message 10 - typically assigned to panning.
expression
MIDI control message 11 - typically assigned to the expression controller on a MIDI
keyboard.
general 1 – 8
MIDI control messages 16 through 23.
MIDI single
Allows selection of any MIDI control number with
coarse quantization. Input range is 0 to 127. A third pa-
rameter appears,
number to be used.
Release 4.0.1
Eclipse User Manual

External Controllers

"connects" external controllers to the Eclipse. You can make up to sixteeen
EXT#16
through . Let's see how one of these "connections" is made.
EXTERNAL EXT#1
. Select the external control-
(SOURCE)
is fully modulated when a switch connected between ring and sleeve of the rear
are fully modulated when the tip and ring are electrically connected and a
(CNTRL)
, which selects the controller
Page 45 of 66
. Monitor its value with
 to set these up, see page 49
