Dedicated Micros DV-IP Decoder Setup Manual page 36

2. Select the port to be configured
3. From the drop down list select the function to be allocated to the serial port
4. Set the; baud rate, parity, Data bits, stop bits and flow control for the serial device
connected to the DV-IP Decoder.
Note: Refer to the manufacturer's documentation for the correct settings.
5. Remember to save the configuration by selecting Save Settings!
Function
Port
Port Usage
Baud Rate, Parity,
Data Bits, Stop
Bits, Flow Control
Reset
Page 34
Description
This identifies the serial port that is being configured, the DV-IP Decoder currently
supports four communications ports
The port usage identifies the function that will be allocated to each serial port, the options
available are: Off (no serial communication), Debug and General Purpose
These are the serial port settings for the peripheral device to allows communication
between the DV-IP Decoder and the device
This will reset the DV-IP Decoder, ensure all settings are saved before resetting the unit
as any configuration settings made without saving will be removed
Dedicated Micros
