CyberData 010844D Setup Manual page 34

34
SIP Setup Page Items
SIP Server field
SIP User ID field
Authentication ID field
Authentication Password field
SIP Registration field
Unregister on Reboot field
Register expiration (minutes) field
Save button
CyberData Corporation
4. For a quick summary of all of the necessary settings on the SIP Setup page
Table 5-1. For a step-by-step description of the necessary settings, go to
parameter is not listed in
complete this procedure.
5. On the SIP Configuration page
• In the SIP Server field, type the address of the Call Manager box.
• In the SIP User ID field, type the directory number that you wrote down in
4.7, "Create a New Directory Number (DN) and Associate it with the New Phone
• In the Authentication ID field, type the Cisco User ID name that you typed into the
Description field in
• In the Password field, type in a password.
• For SIP Registration, select Yes.
• For the Unregister on Reboot field, select Yes.
• In the Register expiration (minutes) field, type 2.
6. Click on the Save Settings button.
Table 5-1, then your input for that setting parameter is not required to
Table 5-1. SIP Setup Page Settings
Setting
Type the address of the Call Manager box.
Type the directory number that you wrote down in
Step 2 of Section 4.7, "Create a New Directory
Number (DN) and Associate it with the New Phone
Device".
Type the Cisco User ID name that you typed into the
Description field in
New User in Cisco Call
Type in a password.
NOTE: Be sure to type a password at the login prompt
or else the speaker will not be registered after the
reboot in this procedure.
Select Yes.
Select Yes.
Type 2.
Click on the Save button only after you have finished
configuring all of the settings on the SIP Setup page.
(Figure 4-35), complete the following steps:
Step 3 of Section 4.5, "Setup a New User in Cisco Call
930280B
(Figure 4-35), see
Step 5. If a setting
Step 3 of Section 4.5, "Setup a
Manager".
Step 2
Manager".
Server Setup Guide
of Section
Device".
