Figure 1-2: 4125 Series Towfish, Topside, And Tow Cable - Edgetech 4125 SIDE SCAN User Manual

Tow cable Shackle
Shackle
Stainless steel
housing
Shear pin
Laptop computer
4125-P Portable
Topside Processor
4125-P Portable Topside Processor with Laptop Computer

Figure 1-2: 4125 Series Towfish, Topside, and Tow Cable

Kellems grip
Towing arm
Tie wraps
4125 Tow vehicle
Tow cable
Shear pin
Safety cable
Safety cable
Waterproof
splice
Tow cable
connector
Port transducer array
1-5
Tow cable
connector
