C-90
C C .2.72 Config. 72: 4125 + Depressor Wing, A302799 Cable - 500m Long
0
-50
-100
6 kts
5 kts
-150
4 kts
-200
-250
-300
-500
0
-50
-100
-150
-200
-250
Tow Fish - 4125 Telemetry + Depressor
-300
0 50
4125 SIDE SCAN SONAR SYSTEM
Tow Cable Shape & Tow Fish Position
3 kts
2 kts
-450 -400 -350 -300
Position Aft of Tow Vessel (m)
Tow Cable Length vs Depth
Tow Cable - p/n A302799,
Length - 500m
100 150 200
Tow Cable - p/n A302799,
Length - 500m
Tow Fish - 4125 Telemetry + Depressor
-250 -200 -150
250 300 350
Cable Length (m)
-100 -50 0
6 kts
5 kts
4 kts
3 kts
2 kts
400 450 500
0004823_REV_C
