C C .2.23 Config. 23: 4125 + 15 lb. Keel Weight, A304874 Cable - 200m Long
0
-20
-40
6 kts
5 kts
-60
4 kts
-80
-100
-120
-140
-200
0
-20
-40
-60
-80
-100
-120
Tow Fish - 4125 Telemetry + 15 lbf Wt.
-140
0 20
Tow Cable Shape & Tow Fish Position
3 kts
2 kts
-180 -160 -140 -120
Position Aft of Tow Vessel (m)
Tow Cable Length vs Depth
Tow Cable - p/n A304874,
Length - 200m
40 60 80
Cable Length (m)
Tow Cable - p/n A304874,
Length - 200m
Tow Fish - 4125 Telemetry + 15 lbf Wt.
-100 -80 -60
100 120 140 160
C-41
-40 -20 0
6 kts
5 kts
4 kts
3 kts
2 kts
180 200
