5-14
ASSY SUB CABLE POWER AC 4125P, 0002531
ASSY CABLE 4125 DC POWER, 0007478
LAPTOP PC DI EDGETECH, 0009897
ASSY SUB CABLE 4125 ETHERNET OUTPUT, 0008563
PLATE BAFFLE 4125P AL, 0007676
PCB ASSY TOP POWER SEP 4125 TOPSIDE, 0008564
ASSY SUB MODEM 4125 VDSL ZYTEL LED CONNECTION, 0009299

Table 5-3: Part Numbers for Major 4125-P Topside Processor Components

5 5 .9

Part Numbers for Major Tow Vehicle Components

The major 4125 Tow Vehicle components and their part numbers are listed below:
DESCRIPTION, PART NUMBER
NOSE END CAP 4125 LT SS, 0008546
NOSE 4125 SS, 0007536
TUBE FRONT 4125 GEN2 SS, 0007540
TAIL CONE 4125, 0007543
FIN TAIL 4125 316 SS, 0007542
THUMBSCREW 4125 TAIL END CAP 316 SS, 0007545
HARDWARE WASHER STD 0.562 INCH ID 1.375 INCH OD
RUBBER, 0007197
RAIL TOW LONG 4125 SHORT CABLE 316 SS, 0008370
RAIL TOW SHORT 4125 SHORT CABLE 316 SS, 0008371
PIN SHEAR 4125 TOW FISH 0.25 INCH DIA DELRIN,
0007538
HARDWARE SHACKLE BOW 5/16 SB 216 316 SS, 0006635
4125 SIDE SCAN SONAR SYSTEM
DESCRIPTION, PART NUMBER
W/O ADDITIONAL
TELEMETRY OPTION
400/900 kHz
X
X
X
X
X
X
X
X
X
X
W/ ADDITIONAL TELEMETRY
OPTION
600/1600 kHz 400/900 kHz
X
X
X X
X X
X X
X X
X X
X X
X X
X X
X X
0004823_REV_C
600/1600 kHz
X
X
X
X
X
X
X
X
X
X
