S S ECTION 3:
Setup and test of the EdgeTech 4125 Series Dual-frequency Side Scan Sonar System encompasses
unpacking, inspecting, and connecting the system components (including an optional printer); connecting
a navigation system if required; activating the system; and verifying operation using the EdgeTech
DISCOVER 4125 Side Scan Sonar software. This section provides instructions on how to perform these
tasks, along with how to deploy, tow, and recover the tow vehicle.
3.1

Unpacking and Inspection

The tow vehicle is shipped in a foam-lined Pelican Storm Case. The 4125-P Portable Topside Processor is
shipped in a cardboard box with its associated cables, including the tow cable, depending on its length.
Before unpacking the system components, inspect the shipping containers for any damage. Report any
damage to the carrier and to EdgeTech.
If the shipping containers appear free of damage, carefully unpack the components and inspect them for
damage as well. Also check the packing list, verifying that all the items on the list are included. Again, if
any damage is found, report it to the carrier and to EdgeTech. If any items are missing, immediately
contact EdgeTech Customer
Although the items shipped will vary, depending on the customer requirements, the 4125 Series Dual-
frequency Side Scan Sonar System typically includes the items listed below.
4125-P Portable Topside Processor
4125 Tow Vehicle
Laptop computer
Laptop computer power supply
50-meter tow cable
AC power cable
DC power cable
ETHERNET cable
Software CDs
Spares kit
After unpacking the system components, store the shipping containers, including any packing materials,
in a safe place for later use. When transporting or storing the system, pack all items in their original
shipping containers in the same manner in which they were originally shipped. Store the system in a dry
environment when not in use.
3.2

Power Requirements

The power requirements for the 4125-P Portable Topside Processor are 90–260 VAC, 50/60 Hz or 12–24
VDC.

SETUP AND ACTIVATION

Service. Do not install or operate any equipment that appears to be damaged.
3-1
