Fuselage Assembly; Hardware Pack; Instruction Manual - Seagull Models CAP 232 Assembly Manual

CAP 232.
INTRODUCTION.
Thank you for choosing the CAP 232 ARTF by SEAGULL MODELS. The CAP 232 was designed
with the intermediate/advanced sport scale in mind. It is a semi scale airplane which is easy to fly
and quick to assemble. The airframe is conventionally built using balsa, plywood to make it stronger
than the average ARTF , yet the design allows the aeroplane to be kept light. You will find that most
of the work has been done for you already. The motor mount has been fitted and the hinges are pre-
installed . Flying the CAP 232 is simply a joy.
This instruction manual is designed to help you build a great flying aeroplane. Please read this
manual thoroughly before starting assembly of your CAP 232. Use the parts listing below to identify
all parts.
WARNING.
Please be aware that this aeroplane is not a toy and if assembled or used incorrectly it
is capable of causing injury to people or property. WHEN YOU FLY THIS AEROPLANE YOU
ASSUME ALL RISK & RESPONSIBILITY.
If you are inexperienced with basic R/C flight we strongly recommend you contact your R/C
supplier and join your local R/C Model Flying Club. R/C Model Flying Clubs offer a variety of training
procedures designed to help the new pilot on his way to successful R/C flight. They will also be able
to advise on any insurance and safety regulations that may apply.
ADDITIONAL ITEMS REQUIRED.
.46- .55 cu.in
.72- .82 cu.in
Radio System required 4 channels
with 6 digital servos.
Glow plug to suit engine
Propeller to suit engine
Protective foam rubber for radio
system
Silicone fuel line
TOOLS & SUPPLIES NEEDED.
Thick cyanoacrylate glue
30 minute epoxy
5 minute epoxy
Hand or electric drill
Assorted drill bits
Modelling knife
Straight edge ruler
2mm ball driver
Phillips head screwdriver
220 grit sandpaper
90° square or builder's triangle
Wire cutters
Masking tape & T-pins
Thread-lock
Paper towels
2
2-stroke
4-stroke

Instruction Manual

PARTS LISTING.

FUSELAGE ASSEMBLY

(1) Fuselage
(1) Canopy
WING ASSEMBLY
(1) Right wing half/ aileron
(1) Left wing half with/ aileron
(1) Aluminium dihedral brace
Tail section assembly
(1) Horizontal stabilizer/ elevator
halves.
(1) Rudder halves.
Some more parts.

HARDWARE PACK

COWLING
Landing gear.....
