INTRODUCTION.
Thank you for choosing the PC-9 ARTF by SEAGULL MODELS. The PC-9 was designed with
the intermediate/advanced sport flyer in mind. It is a low-wing scale aeroplane which is easy to fly
and quick to assemble. The airframe is conventionally built using balsa, plywood and veneer to make
it stronger than the average ARTF , yet the design allows the aeroplane to be kept light. You will find
that most of the work has been done for you already. The pushrods are pre-made to the correct
lengths, the motor mount has been fitted and the hinges are pre-installed and pinned for security.
Flying the PC-9 is simply a joy.
This instruction manual is designed to help you build a great flying aeroplane. Please read this
manual thoroughly before starting assembly of your PC-9 . Use the parts listing below to identify all
parts.
WARNING.
Please be aware that this aeroplane is not a toy and if assembled or used incorrectly it is capable
of causing injury to people or property. WHEN YOU FLY THIS AEROPLANE YOU ASSUME ALL
RISK & RESPONSIBILITY.
If you are inexperienced with basic R/C flight we strongly recommend you contact your R/C
supplier and join your local R/C Model Flying Club. R/C Model Flying Clubs offer a variety of training
procedures designed to help the new pilot on his way to successful R/C flight. They will also be able
to advise on any insurance and safety regulations that may apply.
ADDITIONAL ITEMS REQUIRED.
* .40-.58 2-stroke engine.
* .50-.72 4-stroke engine.
* 4-channel radio with five servos.
* Glow plug to suit engine.
* Propeller to suit engine.
* Protective foam rubber for radio
system.
* Silicone fuel line.
* Stick-on weights for balance
(If necessary).
TOOLS & SUPPLIES NEEDED.
* Thick cyanoacrylate glue.
* 30 minute epoxy.
* 6 minute epoxy.
* Hand or electric drill.
* Assorted drill bits.
* Modelling knife.
* Straight edge ruler.
* 2mm ball driver.
* Phillips head screwdriver.
* 220 grit sandpaper.
* 90° square or builder's triangle.
* Wire cutters.
* Masking tape & T-pins.
* Thread-lock / Paper towels.
PARTS LISTING.

FUSELAGE ASSEMBLY

* (1) Fuselage.
* (1) Pre-installed throttle pushrod &
tube.
* (1) Pre-installed servo tray.
WING ASSEMBLY
* (1) Right wing half with pre-
installed aileron.
* (1) Left wing half with pre-installed
aileron.
* (1) Aluminium wing dihedral
brace.
TAIL SECTION ASSEMBLY
* (1) Vertical stabilizer with pre-
installed rudder.
* (1) Horizontal stabilizer with pre-
installed elevator halves.
