INTRODUCTION
Thank you for choosing the Harrier 3D ARTF by SEAGULL MODELS. The Harrier 3D was designed
with the intermediate/advanced sport flyer in mind. It is a 3D airplane which is easy to fly and quick
to assemble. The airframe is conventionally built using balsa, plywood and veneer to make it stronger
than the average ARTF , yet the design allows the aeroplane to be kept light. You will find that most
of the work has been done for you already. The motor mount has been fitted and the hinges are pre-
installed . Flying the Harrier 3D is simply a joy.
This instruction manual is designed to help you build a great flying aeroplane. Please read this
manual thoroughly before starting assembly of your Harrier 3D . Use the parts listing below to
identify all parts.
WARNING
Please be aware that this aeroplane is not a toy and if assembled or used incorrectly it is
capable of causing injury to people or property. WHEN YOU FLY THIS AEROPLANE YOU
ASSUME ALL RISK & RESPONSIBILITY.
If you are inexperienced with basic R/C flight we strongly recommend you contact your R/C supplier
and join your local R/C Model Flying Club. R/C Model Flying Clubs offer a variety of training
procedures designed to help the new pilot on his way to successful R/C flight. They will also be able
to advise on any insurance and safety regulations that may apply.
ADDITIONAL ITEMS REQUIRED
.61-1.00 2-stroke engine
.91-1.10 4-stroke engine
Computer radio with six servos
Glow plug to suit engine
Propeller to suit engine
Protective foam rubber for radio
system
Silicone fuel line
TOOLS & SUPPLIES NEEDED
Thick cyanoacrylate glue
30 minute epoxy
5 minute epoxy
Hand or electric drill
Assorted drill bits
Modelling knife
Straight edge ruler
2mm ball driver
Phillips head screwdriver
220 grit sandpaper
90° square or builder's triangle
Wire cutters
Masking tape & T-pins
Thread-lock
Paper towels
2
Instruction Manual
PARTS LISTING

FUSELAGE ASSEMBLY

(1) Fuselage
(1) Canopy hatch
WING ASSEMBLY
(1) Right wing half with pre-installed
aileron
(1) Left wing half with pre-installed
aileron
(2) Aluminium dihedral brace
Tail section assembly
(1) Vertical stabilizer with pre-
installed rudder
(1) Horizontal stabilizer with pre-
installed elevator halves
Some more parts.

HARDWARE PACK

COWLING
Landing gear.....
