Getting Started

Setting Paper on the Bypass Tray

This section gives instructions for setting paper on the optional bypass tray. Use
the bypass tray to print onto OHP transparencies, labels, and envelopes that can-
1
not be loaded in the paper tray.
Reference
For setting paper into the regular paper tray, see the General Settings Guide.
Note
❒ The paper size that can be set in the bypass tray:
• Vertical: 90 - 297 mm (3.5 in. - 11.7 in.)
• Horizontal: 148 - 432 mm (5.8 in. - 17 in.)
❒ Make sure to set the paper in landscape orientation L in the bypass tray.
Important
❒ When printing using the printer function, original images are always rotated
by 180 degrees (the orientation of images to be printed is opposite to that of
the copier function). When printing onto paper with specific orientation re-
quirements, such as envelopes and letterheads, make sure to rotate the paper
feed direction to 180 degrees.
❒ The following functions are disabled when printing from the bypass tray:
• Duplex Printing
• Auto Tray Select
• Auto Tray Switching
❒ Make sure to set the paper size using the printer driver when printing data
from the computer. The paper size set using the printer driver has priority
over the one set using the display panel.
❒ Make sure to set the paper to landscape orientation L in the printer driver
when printing data from the computer.
A A A A
Open the bypass tray.
14
ZGPH100E
