VoloAccess™

Local Area Network (LAN)

Network cable is not connected
Network cable is connected to the VoloAccess and
a LAN is present
Network traffic is detected

Wide Area Network (WAN)

Network cable is not connected to the WAN port
Network cable is connected to the WAN port and a
WAN is present
WAN network traffic is detected

Phone 1 / Phone 2

Phone is On Hook and idle
Phone is Off Hook
Phone is receiving a call or dialling out

Power up sequence

During start up, the VoloAccess flashes the WiFi Protected Setup, Signal Strength and Mobile Network
indicators at 1 second intervals for about 10 seconds.
Copyright © Vololink Pty Ltd 2006-2010
Status
Status
Status
LAN Indicator
OFF
– solid
ON
– flashing
ON
WAN Indicator
OFF
– solid
ON
– flashing
ON
Phone 1 / Phone 2 Indicators
OFF
– flashing at 1 second intervals
ON
– flashing at 1 second intervals
ON
V1.43 July 2010
User Manual
Page 11 of 78
