NOTE:
• For a problem with the local disk array's Command View XP management station or Command View
XP or XP Remote Web Console software, see the Troubleshooting chapter of the HP StorageWorks
Command View XP user guide for XP Disk Arrays or the HP StorageWorks XP Remote Web Console
user guide for XP12000/XP10000.
• For additional assistance, contact your HP account support representative.
Table 11

General External Storage XP troubleshooting

Error
The Command View XP
management station or XP
Remote Web Console cannot
access the external LU.
The external LU cannot be
mapped as an internal XP
LDEV of the local disk array.
The path to the external LU is
blocked.
The status appearing in the
Ex-Dev. Status column is
Normal, but the status
appearing in the LDEV Status
is Unknown.
96 External Storage XP for the XP12000/XP10000
Corrective action
Correct the error and retry the operation.
The reason for the error could be one of the following:
• The Fibre Channel (FC) switch is off or an error occurred in the switch.
• The FC cables are not properly connected.
• The configuration of the external disk array changed, and the external LU was
deleted.
• An error occurred with the external LU in the external disk array.
• The path between the local disk array and external disk array changed.
• The port attribute of the local disk array is no longer external.
• The topology information is not set correctly.
If none of these are the problem, disconnect the cable between the local disk
array and external disk array, and reconnect it. Retry the operation after
30 seconds.
Correct the error and retry the operation.
The source of the error could be any of the following:
• The number of mapped external LUs exceeds the maximum number (15,360
LUs for XP12000 or 8,192 LUs for XP10000) available for the local disk
array.
• There are not enough CU:LDEV numbers available for external LU mapping.
An error in the first row of this table (Error: The Command View XP or XP Remote
Web Console cannot access the external LU) could be the reason for this error.
Check the reasons in the first row, correct the error, and retry the operation. If the
error persists, try step 2.
Try the following procedures. If they do not work and the path is not restored, save
the HP disk array configuration information using
HP account support representative.
1. Verify that the cable between the local disk array and external disk array is
connected properly.
2. If the cable between the local disk array and external disk array is connected
properly, disconnect and reconnect it. After 30 seconds, check the path status
from Command View XP or XP Remote Web Console.
The LDEV's status cannot be determined. This occurs when the LDEV does not
exist. The reason for the error could be:
• The LDEV was been created when the volume was mapped.
• The LDEV in the external LU was deleted by the Customized Volume function.
• If LDEV Status becomes Unknown by any reason other than above, contact
you HP account support representative.
FD Dump
and contact your
