Installation Manual for VISIX Network Cameras

Chapter 2 Box Camera Installation

2.1 Box Cameras: Appearance/Description

Camera Description:
Description
Table 2-1
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
3xLOGIC, Inc. •
© 2007-2012 3xLOGIC. Inc. All rights reserved. Information subject to change without notice, 3xLOGIC logo is a trademark of 3xLOGIC, Inc.
Figure 2-1
10M/100M self-adaptive Ethernet interface
VIDEO OUT: Video output interface
AUDIO OUT: Audio output interface
1A, 1B: Alarm output interface
st
6510 West 91 Avenue •
Overview
Description
Lens mount
Back focus ring
SD card slot
Auto-iris interface
POWER: Power LED indicator
Power supply interface
MIC IN: Audio input interface
D+, D-: RS-485 interface
IN, G: Alarm input interface
Ground
RESET: Reset button
