VISIX VIDEO SOLUTIONS | QUICK START GUIDE

VISIX VX-5M(28)(4)-OT-(R)IW

5MP Turret Cam

Quick Start Guide

v1.0.0

3XLOGIC, INC. | USA: 11899 EXIT 5 PARKWAY, SUITE 100 FISHERS, IN 46037 | UK: 15 COFTON RD, EXETER, EX2 8QW, UK |

EU: ELIMAENKATU 13B, 00520 HELSINKI, FINLAND

NOTICE. 3XLOGIC AND THE 3XLOGIC AND VIGIL LOGOS ARE TRADEMARKS OF 3XLOGIC, INC. ALL OTHER TRADE-MARKS

ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS.

Table of Contents

Need help?

Do you have a question about the VISIX VX-5M-OT-RIW and is the answer not in the manual?

Questions and answers

Summary of Contents for 3xLogic VISIX VX-5M-OT-RIW

Page 1 Quick Start Guide v1.0.0 3XLOGIC, INC. | USA: 11899 EXIT 5 PARKWAY, SUITE 100 FISHERS, IN 46037 | UK: 15 COFTON RD, EXETER, EX2 8QW, UK | EU: ELIMAENKATU 13B, 00520 HELSINKI, FINLAND ©2024 3XLOGIC, INC. ALL RIGHTS RESERVED. INFORMATION IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
Page 2 QUICK START GUIDE | VX-5M(28)(4)-OT-(R)IW COMPLIANCE CAN ICES-3 (A) / NMB-3(A) E467564 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions i. This device may not cause harmful interference. ii. This device must accept any interference received, including interference that may cause undesired operation.
Page 3 QUICK START GUIDE | VX-5M(28)(4)-OT-(R)IW PRE-INSTALL AND SAFETY GUIDELINES Note: These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. If the product is not functioning properly or damaged, contact the service center or purchasing office.
Page 4 QUICK START GUIDE | VX-5M(28)(4)-OT-(R)IW POWER 1. Disconnect the power plug from the outlet before connecting to the power terminal block. Connect the device to the power line after fixing it firmly to the power connection terminal. Connect the power plug to the outlet to power the device.
Page 5 QUICK START GUIDE | VX-5M(28)(4)-OT-(R)IW INSTALLATION AND USE PRECAUTIONS 1. Do not disassemble the camera at your discretion. 2. If you forcefully install the product with excessive force, malfunction can damage the camera. 3. Do not punch or shake the camera and be careful not to damage the camera with careless storage or mal- function.
Page 6 QUICK START GUIDE | VX-5M(28)(4)-OT-(R)IW PREPARING TO MOUNT THE CAMERA 1. The mounting surface must bear ﬁve times the weight of your camera. 2. Do not let the cables get caught in improper places or the electric line cover to be damaged. This may cause a breakdown or ﬁre.
Page 7: Product And Accessories
QUICK START GUIDE | VX-5M(28)(4)-OT-(R)IW 1 PRODUCT & ACCESSORIES Note: Confirm all camera parts and accessories are included in the package. VX-5M(28)(4)-OT-(R)IW MOUNT TEMPLATE HEX WRENCH QUICK GUIDE SCREWS AND ANCHORS WATERPROOF CAP AND GASKETS (2x)
Page 8: Part Names
QUICK START GUIDE | VX-5M(28)(4)-OT-(R)IW 2 PART NAMES PART DESCRIPTION IR LED Lens (Fixed or Remote Focus, Model Dependent) Camera Panning Screw DC12V Power Jack Waterproof Cap RJ45 / LAN Connector Cable Guide Rubber Placeholder Camera Tilt / Rotate Screw...
Page 9: Installation
QUICK START GUIDE | VX-5M(28)(4)-OT-(R)IW 3 INSTALLATION Before installing you must read the following cautions. Confirm the installation location can bear five times of the weight of your camera. Do not allow the cabling to be caught, pinched or snagged on the environment or the electric line cover to be damaged.
Page 10: Camera Installation
QUICK START GUIDE | VX-5M(28)(4)-OT-(R)IW 3.2 CAMERA INSTALLATION 1. Disassemble the camera. See "Disassembling the Camera" on the previous page for details. 2. Using the template sheet, drill the cabling passthrough hole into the mounting surface. 3. Connect the network cable and power cable respectively. See "Cabling"...
Page 11 QUICK START GUIDE | VX-5M(28)(4)-OT-(R)IW 4 CABLING 4.1 CONNECTING LAN (RJ45) CABLE 1. Pass the LAN cable through the (a) lid. 2. Insert the cap into the slit in the (b) rubber. When inserting the cap choose either the available 4.5Ø or 5.5Ø rubber sizes.
Page 12: Camera Cabling
QUICK START GUIDE | VX-5M(28)(4)-OT-(R)IW 4.2 CAMERA CABLING 1. Network Connection (RJ45 / LAN) Connect RJ45 cable.. See "Connecting LAN (RJ45) Cable" on the previous page for more info. ■ Max Distance - 100m ■ PoE - IEEE 802.3af 2. DC12V Power Connection - Confirm supply voltage before connecting. Two options exist for providing the camera with power and a network interface.
Page 13: Step 2: Select Camera
QUICK START GUIDE | VX-5M(28)(4)-OT-(R)IW 5 CAMERA SETUP (ADD CAMERA TO VIGIL) STEP 1: RUN DETECTION UTILITY / IDENTIFY CAMERAS i. On your VIGIL Server system, open the VIGIL Server Management Utility (VSMU) and nav- igate to the Cameras tab (open by default). ii.
Page 14 STEP 7: ADVANCED OPTIONS / FACTORY RESET / REBOOT If advanced configuration of camera image(and other) settings is required, see the latest version 3xLOGIC VISIX Gen III User Guide for more information on accessing and configuring these settings via the camera's browser UI.
Page 15 After adding the camera to VIGIL Server or setting the camera up as a standalone device (applicable models only), 3xLOGIC recommends VIGIL Client for viewing live and playback. Client’s powerful toolset can be leveraged by users to thoroughly and quickly review camera footage and other data collected by a VIGIL Server or VIGIL All-in- One camera.
Page 16 For further details on reviewing and exporting playback and other advanced features such as audio record- ing and two-way audio talk, POS Data OSD and more, please visit www.3xlogic.com and consult the product documentation library for VIGIL Client-related support documentation.
Page 17: Contact Information
QUICK START GUIDE | VX-5M(28)(4)-OT-(R)IW 7 CONTACT INFORMATION 3xLOGIC has offices in Fishers, Indiana, USA as well as Exeter, UK and Helsinki, FInland. Please visit our 3xLOGIC website at www.3xlogic.com. Please contact us by e-mail at helpdesk@3xlogic.com (technical support), or using...
Page 18: Disposal Of Old Appliance
3. The correct disposal of your old appliance will help prevent potential negative con- sequences for the environment and human health. 4. For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop where you purchase the product. 3xLOGIC.com helpdesk@3xlogic.com...
