Installation Manual for VISIX Network Cameras

Chapter 3 Dome Camera Installation

3.1 Dome Cameras: Appearance/Description

Camera Description:
Description
Table 3-1
No.
1
2
3
4
5
6
7
8
Note: After the powering on of the camera, pressing and holding the INITIAL SET button for about
10 seconds can reset all the parameters to the default settings.
3xLOGIC, Inc. •
© 2007-2012 3xLOGIC. Inc. All rights reserved. Information subject to change without notice, 3xLOGIC logo is a trademark of 3xLOGIC, Inc.
Figure 3-1
10M/100M self-adaptive Ethernet interface
AUDIO OUT: Audio output interface
1A, 1B, 2A, 2B: Alarm output interface
IN1, GND, IN2, GND: Alarm input interface
st
6510 West 91 Avenue •
Overview
Description
INITIAL SET: Reset button
MIC IN: Audio input interface
D+, D-: RS-485 interface
Power supply interface
Westminster, CO 80031 • (877) 3XLOGIC • www.3xlogic.com
11
