3xLogic VISIX Installation Manual page 15

Installation Manual for VISIX Network Cameras
In-ceiling Mounting:
Steps:
1. Secure the mounting base to the in-ceiling mounting base with screws.
2. Push the dome camera to the in-ceiling mounting base, rotate the dome camera for 10 degrees
counterclockwise and then fasten the lock screws to fix the camera.
①
3xLOGIC, Inc. •
© 2007-2012 3xLOGIC. Inc. All rights reserved. Information subject to change without notice, 3xLOGIC logo is a trademark of 3xLOGIC, Inc.
Secure the Mounting Base
Figure 3-8
Figure 3-9
st
6510 West 91 Avenue •
②
Fix the Camera
Westminster, CO 80031 •
In-ceiling
Mounting
Base
Mounting Base
(877) 3XLOGIC • www.3xlogic.com
15
③
Lock screw
