Additional Fields
Up to five additional fields can be created for each editing format; each of them is numbered from
AF1 to AF5 accordingly.
If "BT HID", "USB HID" or "Keyboard Wedge" is configured for interface, Key Type and Key
Status will then become applicable. You may decide whether or not to apply Key Status when
"Normal Key" is selected for Key Type.
Key Type
Scan Code Up to 2 scan code values are allowed.
Normal Key Up to 4 character strings are allowed.
1. Read the barcode below to specify an additional field, one at a time.
2. Read the "Hexadecimal
3. Read the "Validate" barcode to complete this setting.
Value" barcode on page 228 for the desired additional field.
Chapter 6 Applying Formats for Data Editing
Key Status
N/A
Add Shift
Add Left Ctrl
Add Left Alt
Add Right Ctrl
Add Right Alt
Refer to Keyboard Wedge
Additional Field 1...
Additional Field 2...
Additional Field 3...
Additional Field 4...
Additional Field 5...
Update
Table.
199
