Chapter 3

C/T PORT

C/T PORT
C/T PORT

Device Address

Image Buf Size

Report Status

C/T PORT Submenus

Port Type
This menu item selects the desired active CTHI interface and appears only
when the CTHI option is installed.
The factory default is Twinax.
Device Address
Allows you to set the device address from 0 through 6. The host directs data
and commands on the twinax line to a specific device based on its unique
device address. After the address has been changed, a Power On Reset
(POR) status is sent to the host.
The factory default is 1.
Image Buf Size
Allows you to select 4K or 2K as the image buffer size. This option is only
valid when the printer emulates 3287. For the 4234 emulation, the buffer size
is fixed at 4K. A POR status is sent to the host when the printer is put online.
The factory default is 4K.
216
(1)
Port Type
Twinax*
Address 1*
4K*
Timeout
10 sec.*
Disable*
Notes:
* = Factory Default
1
Coax Disable
Address 0-6
2K
5-60 sec.
Enable
Appears only if the CTHI option is installed.
