Ver Image Shift

This option specifies the amount to shift an image vertically up (-) or down (+)
for precise positioning on the label. The actual height of the image is not
affected by this parameter. The allowable range is -1.00 inches to the current
Label Length value setting up to a maximum of 12.80 inches in .01 inch
increments.
The factory default value in inches is 0.00 inches.
Hor Image Shift
This option specifies the amount to shift an image horizontally left (-) or right
(+) for precise positioning on the label. The actual width of the image is not
affected by this parameter. The allowable range is -1.00 through +1.00 inches
in .01 inch increments, displayed as xx/100. The factory default value in
inches is 0.00.
Orientation
This menu item selects the image orientation to be used when printing the
label.
•
Portrait. Portrait refers to vertical page orientation, where the height of a
page is greater than its width. The top edge of the image is parallel to the
leading edge of the media. The following illustration is an example, with
the operator viewing the front of the printer.
FEED
MEDIA CONTROL Submenus
4"
6"
Leading Edge
