Chapter 3
MEDIA CONTROL

Num Auto Labels

The desired number of labels to be printed vertically adjacent on the form.
The value is selectable with a range of 1 through 40 (T5X04), 1 through 21
(T5X06) and 1 through 17 (T5X08).
The factory default is 2.
Slew Speed
This option selects the speed at which media will be advanced after the
printer determines there is no more data to be printed on a label.
The range is 2-10 ips, and the factory default is 6 ips.
Print Direction
This option determines the basic print image orientation.
NOTE: Print Direction will not change the orientation of any print test patterns
Print Direction has two options:
•
Head First
•
Foot First
For example, with Portrait orientation, when you select Head First, the top-of-
form will come out of the printer first. Conversely, when you select Foot First,
the bottom-of-form will come out first.
The Print Direction and Orientation are two independent options that can be
combined to produce the following results depending on the Active IGP
Emulation:
Print Direction
Head First
Head First
104
in the DIAGNOSTIC Main Menu.
FEED
Head First
Table 3. Head First
Orientation Option
Option
Portrait
Landscape
A
Foot First
Result in Active IGP Emulations
(IGP/PGL or IGP/VGL)
Portrait
Landscape
