Initial Power-Up

1. Place a small screwdriver blade between the
pins on the control panel PCB, marked
FACTORY RESTART (located just below the LEDs).
This will ensure the factory defaults are loaded
as shown below:
Engineer Code
User Code 1
Zone 1
Zone 2
Zone 3
Zone 4
Zone 5
Exit Time
Entry Time
Bell Duration
Bell Output
Remote Reset Number
Setting Mode
Reset Authority
Number Of Rearms
Operation Of Keyswitch
RST- Output
HOME Set Configuration
Factory Default Settings
2. Switch on the 240V mains supply, when the
green UNSET LED is lit remove the screwdriver
blade. The internal alarm will sound and the
TAMPER LED will light.
3. Enter the engineer's passcode (default 1 2 3 4),
the alarm will silence. Enter the engineers
passcode again and the TAMPER LED will flash
(engineer programming menu selected).
4. Connect the standby battery. If the TAMPER
LED lights permanently and the internal alarm
sounds when the battery is connected, then it
may be incorrectly connected or it may be
totally discharged. Disconnect the battery
immediately and reconnect or replace as
appropriate.
5. Push the battery into place at the bottom of the
housing and re-fit the front cover.
1234
5678
Alarm
Access
Alarm
Alarm
Alarm
30 Seconds
30 Seconds
20 Minutes
SAB (-ve applied)
004
Timed Set
User Reset
3
Away Set (Full)
Detector Reset
Zone 1 Omitted
+
On the TS410 you MUST connect the earth
bonding cable from the front cover to the
spade connection point, see figure 2.
6. Fit the battery link in the external sounder and
replace cover.
7. The system is now ready for programming.
