S
PECIFICATIONS
VIDEO
Gain .................................................. Selectable: 0.7V (unity), or 0.75V
Peaking ............................................ Selectable: 0dB or 6dB @100 MHz
Bandwidth ........................................ 350 MHz (-3dB)
VIDEO INPUT
Number/signal type .......................... 1 VGA-UXGA RGBHV, RGBS, RGsB, RsGsBs
Connectors........................................ (1) 15-pin HD female
Nominal level .................................... 0.7V p-p for RGB
Minimum/maximum levels ................ Analog: 0.3V to 1.5V p-p with no offset at
Impedance ........................................ 75 ohms
Horizontal frequency ........................ 15 kHz to 135 kHz
Vertical frequency.............................. 30 Hz to 170 Hz
Return loss ........................................ <-38dB @ 5 MHz
Maximum DC offset.......................... 1.0V
AC/DC coupling................................ No

VIDEO OUTPUT

Number/signal type .......................... 1 VGA-UXGA RGBHV, RGBS, RGsB, RsGsBs
Connectors........................................ (2) 15-pin HD female
Nominal level .................................... 0.7V p-p for RGB
Minimum/maximum levels................ Analog, 0.3V to 1.5V p-p
Impedance ........................................ 75 ohms
Return loss ........................................ <-40dB @ 5 MHz
DC offset .......................................... ±5mV maximum with input at 0 offset
SYNC
Input type ........................................ RGBHV, RGBS, RGsB, RsGsBs
Output type ...................................... RGBHV, RGBS, RGsB, RsGsBs
Input level ........................................ Analog or TTL, 0.5V to 5.0V p-p
Output level ...................................... TTL, 5.0V p-p, unterminated
Input impedance .............................. 510 ohms
Output impedance............................ 75 ohms or 55 ohms, switchable (output
Max. input voltage............................ 5.0V p-p
Max. propagation delay .................... 60 ns
Max. rise/fall time ............................ 4 ns
Polarity.............................................. Positive or negative (follows input)
AUDIO — P/2 DA2XI MT ONLY
Gain .................................................. Unbalanced output: 0dB; balanced output:
Frequency response .......................... 20 Hz to 20 kHz, ±0.05dB
THD + Noise .................................... 0.03% @ 1 kHz at nominal level
S/N .................................................. >90dB (balanced) at rated maximum output
Crosstalk .......................................... <-80dB @ 1 kHz, fully loaded
Stereo channel separation ................ >80dB @ 1 kHz, >60dB @ 20 kHz
CMRR................................................ >75dB @ 20 Hz to 20 kHz
AUDIO INPUT — P/2 DA2XI MT ONLY
Number/signal type .......................... 1 stereo, unbalanced
Connectors ...................................... (1) 3.5 mm stereo jack, female; tip (L), ring
Impedance ........................................ >5 kohms unbalanced, DC coupled
Nominal level .................................... -10dBV (316mVrms)
Maximum level ................................ +10dBV (3.16V) (unbalanced) at 1%THD+N
input
unity gain
output
1 VGA-UXGA RGBHV, RGBS, RGsB, RsGsBs
local monitor loop-through
(I.D. bits are passed through)
impedance resistors are 50 and 30 ohms)
+6dB
(R), sleeve (GND)
AUDIO OUTPUT — P/2 DA2XI MT ONLY
Number/signal type .......................... 1 stereo, balanced/unbalanced
Connectors........................................ (1) 3.5 mm captive screw connector, 5-pole
Impedance ........................................ 50 ohms unbalanced, 100 ohms balanced
Gain error.......................................... ±0.1dB channel to channel
Nominal level .................................... -2dBu (632mV) balanced output -10dBV
Maximum level (Hi-Z) ...................... >+18dBu, balanced or unbalanced at stated
Maximum level (600 ohms) .............. >+12dBm, balanced or unbalanced at stated
NOTE: 0dBu = 0.775 volts (RMS). 0dBV = 1 volt (RMS).
GENERAL
Power................................................ P/2 DA2xi requires 0.1 A, and P/2 DA2xi MT
Rack mount ...................................... Yes, with optional 1U rack shelf,
Enclosure type .................................. Metal
Enclosure dimensions ........................ 1.0" H x 4.3" W x 3.0" D (quarter rack width)
Product weight ................................ 0.5 lbs (0.3 kg)
Shipping weight................................ 3 lbs (1.4 kg)
Listings.............................................. UL, CUL
Compliances .................................... CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ................................................ 30,000 hours
Warranty .......................................... 3 years parts and labor
Model
P/2 DA2xi.......................................... 60-506-01
P/2 DA2xi MT .................................. 60-506-21
Included Accessories
User guide
Tweeker
Desktop power supply
VGA cable clip
6' M-M VGA cable
(P/2 DA2xi only) .......................... 26-533-02
6' M-M VGA/audio cable
(P/2 DA2xi MT only) .................... 26-490-02
5-pin captive screw mating plug
(P/2 DA2xi MT only)
Optional Accessories
VersaTools rack shelf kit .................... 60-190-20
Universal rack shelf kit ...................... 60-190-01
Under-desk mounting kit .................. 70-077-01
Projector mounting kit ...................... 70-077-04
T-VGA adapter .................................. 26-106-01
VGA M3' MHRA cable ...................... 26-490-01
VGAM12' MHRA cable ...................... 26-490-03
Specifications are subject to change without notice
(316mV) unbalanced output
% THD +N
% THD +N
requires 0.2 A via pin 9 of the VGA input of a
PC
that complies with VESA DCC version 3 or
100VAC
to 240VAC, 50/60 Hz, 5 watts, external,
autoswitchable; to 12VDC, 1 A power supply.
part #60-190-01,
or the VersaTools™ rack shelf,
part #60-190-20; also under-furniture
mountable with optional brackets #70-077-01
or projector mountable with optional brackets
#70-077-04.
2.5 cm H x 10.9 cm W x 7.6 cm D (Depth
excludes connectors.)
